Summary of Contents for Samcon ExCam IPP5655 MKII

  • Page 1 ® ExCam IPP5655 MKII User Manual...
  • Page 2: Table Of Contents

    Table of contents Introduction ......................4 Technical data ......................4 Explosion protection .................... 4 Illustration of the model key ................. 5 Electrical parameters of the camera ..............6 Connection cable Ex-d - Ex-e (SKD02-T/ASKD02-T) .......... 6 Video-technical characteristics ................7 Other technical data ....................
  • Page 3 Fig. 2-2 Sectional view of ASKD02-T ................7 Tab. 2-2 Other technical data .................... 7 Tab. 4-1 Mounting accessories ..................11 Fig. 5-1 ExCam IPP5655 MKII equipotential bonding ............12 Tab. 5-1 Equipotential Bonding ..................13 Fig. 5-2 Video Tutorial ExTB-2 ..................14 Tab.
  • Page 4: Introduction

    Introduction In the ExCam IPP5655 MKII is a powerful IP dome camera of the latest generation, with 2- megapixel resolution at 1920x1080p points. It is certified by ATEX, IECEx, INMETRO, EAC-Ex (and more). This dome camera can endlessly rotate around its own axis. This is done with a high speed and precision.
  • Page 5: Illustration Of The Model Key

    L.H- 005.A- 23040147 Tab.2-1 – Model key Explanations: ExCam IPP5655 MKII= Functional camera description of the ExCam Series (technical data/ specification of the individual camera module) T08 = SAMCON Production- Type 08 VA4.1K.PS1 = Housing combination (Edelstahl 1.4404) with large diameter Ø...
  • Page 6: Electrical Parameters Of The Camera

    Data line: 4 x 2 x AWG23/1 CAT.6 Properties: PUR halogen-free, flame-retardant, UV-re- sistant, chemical resistance, shielded Quick link: https://www.samcon.eu/fileadmin/documents/en/60-Assembling%26mounting/SKD02-T_Datasheet.pdf Fig. 2-1 Sectional view of SKD02-T Systemcable ASKD02-T: Outside diameter: 12.0 ± 0.4 mm Bending radius: 20 x D...
  • Page 7: Video-Technical Characteristics

    Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKD02-T_Datasheet.pdf Fig. 2-2 Sectional view of ASKD02-T Video-technical characteristics We use the AXIS P5655 Dome Camera in a pressure-resistant enclosure. For details, ® please refer to the Product Documentation, video-technical data of AXIS http://www.axis.com/products/axis-p5655-e Other technical data Camera (Ex-d) Terminal box (Ex-e) -30°C …...
  • Page 8: Safety Instructions

    The camera is to be operated in sound conditions and in the intended way. Attention! Only original parts of SAMCON Prozessleittechnik GmbH may be used for repairs. Repairs concerning the explosion protection may only be carried out in accordance with the nationally applied regulations and by SAMCON Prozessleittechnik GmbH.
  • Page 9 Attention! The ExCam devices with model key T08-VA4.1K.PS1 (optical thermo- plastic) must generally not be used for applications in the mining in- dustry (ATEX group I), nor in other hazardous areas with potentially "high" risk of damage caused by mechanical stresses (ATEX group II)! Attention! Risk of electrostatic charging! Clean only carefully with a soft, damp cloth.
  • Page 10: Installation

    Installation For erecting and operating the camera, the relevant national regulations, as well as the generally accepted rules of technology shall prevail. Before mounting the camera, thor- oughly check it for any transport damage, especially regarding the housing and the cable. Installation, electrical connection and the commissioning must only be carried out by qual- ified specialists.
  • Page 11 Please pay attention to the national and local regulations for mounting heavy loads. In case of doubt, take appropriate security measures. Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/network/excam-ipp5655-mkii/ Option mounting accessories WALL MOUNT EXCAM V4.X Wall bracket Wall bracket for the T08-TNXCD and VA4.X series...
  • Page 12: Electrical Connection

    The user is NOT authorised to do any electrical connection procedures inside the pressure-resistant enclosure. Equipotential bonding/Grounding Fig. 5-1 ExCam IPP5655 MKII equipotential bonding Doc.-ID: 240620-PT08BA-ES-ExCam IPP5655 MKII_en_rev.00.docx, Page 12 of 28...
  • Page 13: Connection Work On The Device (Terminal Box)

    (Ex-e). Attention! Adhere to attached separate Usual Manual for the Ex-e connection chamber. Video Tutorial: Observe our video tutorial: “SAMCON 01 Installation and Wiring Connection to ExTB-3” https://go.samcon.eu/v01 Doc.-ID: 240620-PT08BA-ES-ExCam IPP5655 MKII_en_rev.00.docx, Page 13 of 28...
  • Page 14 Fig. 5-2 Video Tutorial ExTB-2 The pin assignment of the SKD02-T is executed in accordance with the standard EIA/TIA- 568B for 100BaseTX as follows: Camera (Ex-d) Colour Terminal Cross-sec- Comment (T568B) SKD02-T ExTB-2 tional sur- face (IEC60757) WH / OG 0.32 mm Solid conductor 0.32 mm...
  • Page 15 Bring the twisted pair composite approximately 10mm close to the ter- minals, in order to ensure the immunity to disturbance. Attention! Use only terminals approved by SAMCON. Attention! Finally, check your network installation by per Class-D Link Test. Doc.-ID: 240620-PT08BA-ES-ExCam IPP5655 MKII_en_rev.00.docx, Page 15 of 28...
  • Page 16: External Connection And Protection

    5.2.2 External connection and protection There are several options of assigning the ExTB-2 terminal box in a safe area: 5.2.2.1 Direct routing from the ExTB-2 into the safe area In the case of direct routing from ExTB-2 into the safe area, the power supply and the voltage signal is led from the safe area to the terminal box.
  • Page 17: Plug Assignment (Rj45)

    5.2.3 Plug assignment (RJ45) The data transfer of the ExCam IPP5655 MKII series uses a 100 Mbit/s Ethernet connec- tion (100BASE-TX). If the cable termination uses a plug it has to be plugged into the associated slot of the network device. Prior to connecting it to the camera, the network device (PSE) can already be supplied with power, hence there is no „power ON“...
  • Page 18: Appropriate Cables & Cable Entries

    We show the essential procedures in the following video tutorial: Video Tutorial: Observe our video tutorial: “SAMCON 02 Installation Ex d gland” https://go.samcon.eu/v02 Doc.-ID: 240620-PT08BA-ES-ExCam IPP5655 MKII_en_rev.00.docx, Page 18 of 28...
  • Page 19: Tests Prior To Switching On Voltage

    Fig. 5-6 Barrier gland Tests prior to switching on voltage Attention! Prior to commissioning, all tests as indicated by the national regula- tions have to be executed. Furthermore, the correct function and instal- lation of the device has to be checked in accordance with this user man- ual and other applicable regulations.
  • Page 20: Opening The Pressure-Resistant Housing (Ex-D)

    If you think that the housing has to be opened for unforeseeable reasons, please contact our support team at first (support@samcon.eu). Opening and closing the pressure-resistant housing Always adhere to the explosion-relevant rules: „WARNING –...
  • Page 21 Carefully pull out the dome flange strictly vertically/perpendicularly (see Figure 6-1). There is a risk of side tilt! Because of negative pressure it may be difficult to remove. H8f7 H8G7 The circular cylindrical clearance fit (in accordance with ISO 286) of the camera body and flange must not be tilted! Risk of damage to the flame-proof gap (DIN EN 60079-1)! Caution: Avoid any contact of the screw thread with skin and clothes! There is oil...
  • Page 22: Removing / Inserting A Sd Memory Card

    Removing / inserting a SD memory card Note: The ExCam IPP5655 MKII has a slot for a micro SDHC memory card (card not included). Saved video files can be played and deleted via the web interface. They are also available in a download list.
  • Page 23: Hardware Reset

    Fig. 6-2 Reset Button / Memory Card Hardware Reset To set all the parameters of the ExCam IPP5655 MKII (including the IP address) to default values, you should run a hardware reset. The parameters can be reset via the web interface or manually. If the camera placed in the network can no longer be reached or its state is uncontrollable, the reset should be per- formed manually.
  • Page 24: Network Access And Visualization

    Interface, please see the User Manual for Axis or visit the following website: http://www.axis.com/products/axis-p5655-e At delivery, the ExCam IPP5655 MKII is set to the applicable net frequency (50Hz or 60Hz). If the camera is used at a location with a differing net frequency, a flickering of the picture might be noticeable, particularly in surroundings with fluorescent tubes.
  • Page 25: Password/ Identification

    It can also be used to manually assign a static IP address. For this pur- pose, the ExCam IPP5655 MKII network camera has to be installed in the same physical network segment (physical subnet) as the computer on which the AXIS IP Utility is running.
  • Page 26: Maintenance/ Modification

    Reparation Reparations must only be carried out with original parts of SAMCON Prozessleittechnik GmbH. Damaged pressure-resistant housings have to be replaced completely. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH.
  • Page 27 If you wish additional technical information, please contact us at: support@samcon.eu Doc.-ID: 240620-PT08BA-ES-ExCam IPP5655 MKII_en_rev.00.docx, Page 27 of 28...
  • Page 28 Schillerstraße 17, 35102 Lohra-Altenvers www.samcon.eu, info@samcon.eu fon: +49 6426 9231-0, fax: - 31...
