IT-ES308-IU
8-ports Unmanaged Industrial Ethernet Switch
Hardware Installation Guide
Introduction:
1
IT-ES308-IU series are a smart plug-and-play industrial Ethernet
switch, which can provide economical solution for your Ethernet.
Its dustproof fully sealed structure(protective case of IP30 level),
over-current, over-voltage and EMC protected redundant double
power input as well as built-in intelligent alarm design can help
system main tenancy personnel monitor the network operation,
which can work reliably in harsh and dangerous environment.
IT-ES308-IU series supports 8 ports10/100Base-T(X), Full/Half
duplex mode, and auto MDI/MDI-X connection.
Packing List:
The IT-ES308-IU switch is shipped with following items.
1. Ethernet switch IT-ES308-IU (plus terminal block) ×1
2. Hardware Installation Guide ×1
3. Product Warranty Statement ×1
4. DIN-Rail setting fittings (wall mounting for optional)
Features:
1. Advanced Ethernet switch technical
2. IEEE802.3/802.3u/802.3x/802.3d, store and forward
3. 10/100M, F/H duplex, MDI/MDI-X auto negotiation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT-ES308-IU Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intellisystem IT-ES308-IU Series

Summary of Contents for Intellisystem IT-ES308-IU Series

  • Page 1 8-ports Unmanaged Industrial Ethernet Switch Hardware Installation Guide Introduction: IT-ES308-IU series are a smart plug-and-play industrial Ethernet switch, which can provide economical solution for your Ethernet. Its dustproof fully sealed structure(protective case of IP30 level), over-current, over-voltage and EMC protected redundant double...

  • Page 2: Panel Layout

    5. Relay output warning for power failure and port break alarm 6. Redundant 24VDC power input (12V～36VDC) 7. Designed for industrial applications. IP30 protection, rugged high-strength metal case Panel Layout: IT-ES308-IU series industry Ethernet switches provide 8 TP ports. Top panel Front panel Bottom panel Back panel...

  • Page 3: Communication Connector

    7. 10/100Base-T(X) ports 8. Mode name 9. Facility run indication LED 10. System alarm indication LED 11. Power input PWR1 LED 12. Power input PWR2 LED Units（mm） Communication connector: IT-ES308-IU series have 5 10/100BaseT(X) Ethernet ports (RJ45) 10/100BaseT(X) Ethernet port...
  • Page 4 The pin out of RJ45 port display as below, connect by UTP or STP. The connect distance is no more than 100m. 100Mbps is used 100Ωof UTP 5, 10Mbps is used 100Ωof UTP 3, 4, 5. RJ45 port support automatic MDI/MDI-X operation. Can connect the PC, Server, Converter and HUB .Pin 1,2,3,6 Corresponding connection in MDI.

  • Page 5: Led Indicator

    MDI-X (Cross over cable) RJ45 (RX+) (TX+) (RX-) (TX-) (TX+) (RX+) (TX-) (RX-) LED Indicator: LED indictor light on the front panel of IT-ES308-IU Series .the function of each LED is described in the table as below. System indication LED State Description Power1 is being supplied...

  • Page 6: Relay Contact

    The two wires attached to the Fault contacts form an open circuit when: (1) IT-ES308-IU series have lost power from one of the DC power inputs, One of the ports for which the corresponding Port alarm DIP Switch is set to ON is not properly connected.

  • Page 7: Switch Settings

    Switch Settings: Provide 10 bits switch for function setting. 1 ～8 alarm enable switch setting. ON show enable, 9 show PWR1 alarm setting .10 show PWR 2 alarm setting. ON show alarm state. Installation： Before installation, confirm that the work environment meet the installation require, including the power needs and abundant space.

  • Page 8: Wiring Requirements

    or not. 3. Insert the top of the DIN-Rail into the slot just below the stiff metal spring. 4. The DIN-Rail attachment unit will insert into place as shown below. Wiring Requirements： Be sure to disconnect the power cord before installing and/or wiring your Ethernet Switch.

  • Page 9: Specifications

    thumb is that wiring that shares similar electrical characteristics can be bundled together. 4. Keep input and output wiring separated. It is strongly advised that you label wiring to all devices in the system when necessary. Specifications: Interfaces RJ45 Ports: 10/100BaseT(X) auto connection, F /H duplex or force work mode, and support MDI/MDI-X connection, 1000V electromagnetism isolation for protection Alarm output interface：...
  • Page 10 Environmental Operating Temperature: -40 to 75°C Storage Temperature: -45 to 85 °C Ambient Relative Humidity: 10% to 95% (non-condensing) Approvals EMI：FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2(ESD), EN61000-4-3(RS), EN61000-4-4(EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 Shock: IEC 60068-2-27 Free Fall: IEC 60068-2-32 Vibration: IEC 60068-2-6 Warranty: 5 years...
