【Summarize】
IT-ES205-IU-G is a kind of unmanaged industrial Ethernet Switches, which supports 5 10/100/1000M RJ45 ports. It adopts fanless, low-power
design, IP30 protection and high tensile corrugated metal shell so that it can perform more stable. It complies with FCC, CE standards and the
design requirements of industrial level 4. Rail-mount installation and the operating temperature range from -40℃ to 75℃ meet the needs of
various industrial field, which can provide reliable, efficient solutions for your Ethernet device connection.
【Packing list】
Please check the packaging and accessories by your first using.
Industrial Ethernet switch ⅹ 1
User manual ⅹ 1
Certificate of quality ⅹ 1
Warranty card ⅹ 1
DIN-Rail
Please inform us or our distributor if your equipments have been damaged or lost any accessories, we will try our best to sat isfy you.
【Features】
Support IEEE802.3, IEEE802.3u, IEEE 802.3ab
Support 5-port 10/100/1000BaseT(X)(RJ45)
Store and Forward switching process type
Plug-and-play , auto MDI/MDI-X connection
Support MAC address learning, aging automatic
12~48V DC power input
Operating temperature: -40~75℃
Industry-standard design, IP40 Protection, high tensile corrugated shell
DIN-Rail mounting
IT-ES205-IU-G
Industrial Ethernet switch
User manual
1
Advertisement
Table of Contents
Related Manuals for Intellisystem IT-ES205-IU-G
Summary of Contents for Intellisystem IT-ES205-IU-G
- Page 1 【Summarize】 IT-ES205-IU-G is a kind of unmanaged industrial Ethernet Switches, which supports 5 10/100/1000M RJ45 ports. It adopts fanless, low-power design, IP30 protection and high tensile corrugated metal shell so that it can perform more stable. It complies with FCC, CE standards and the design requirements of industrial level 4.
- Page 2 Equipment status indicator 10Base-T /100Base-TX /1000Base-TX (RJ45) ports 【Power supply input】 IT-ES205-IU-G top panel provided 3 bit power supply input terminal block, support DC input. Voltage input range is 12 ～48VDC (terminal block defined as: V-, V+). Terminal diagram is as follows:...
- Page 3 Front view Top view Important notice: 1. Power ON operation: first of all, insert power cable’s terminal block into device’s power port, then insert power supply plug into power source 2. Power OFF operation: First off all, unpin power plug, then strike the terminal block, please take care of operation sequence. 【Appearance and dimensions】...
- Page 4 MDI-X BI_DA+/TX+ BI_DB+/RX+ BI_DA-/TX- BI_DB-/RX- BI_DB+/RX+ BI_DA+/TX+ BI_DC+/— BI_DD+/— BI_DC-/— BI_DD-/— BI_DB-/RX- BI_DA-/TX- BI_DD+/— BI_DC+/— BI_DD-/— BI_DC-/— Note：, “TX±”transmit data±, “RX±”receive data±, “—”not use. 10/100Base-T(X) MDI (straight-through cable) 10/100Base-T(X) MDI-X (Cross over cable) Gigabit MDI (straight-through cable)
- Page 5 MDI/MDI-X auto connection makes switch easy to use for customers without considering the type of network cable. 【LED Indicator】 The LED indicator on the front panel of IT-ES205-IU-G can indicate the running system and the operation status, which makes it easy to find and solve problems, the specific meaning of indicator are shown in the table.
- Page 6 actual position; 4. All the cable cannot have break-down and terminal in the middle; 5. Cables should be straight in the hallways and turning; 6. Cable should be straight in the groove, and cannot beyond the groove in case of holding back the inlet and outlet holes. Cables should be banded and fixed when they are out of the groove;...
- Page 7 Mechanical Structure Shell: IP40 protect grade, metal shell Installation: DIN-Rail mounting Size（W×H×D）: 35mm×110mm×95mm Industry Standards EMI: FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2 (ESD), Level 2 Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6 Certifications CE, FCC, RoHS, UL508 (Pending) Warranty: 5 years...
