8-ports Unmanaged Industrial Ethernet Switch
Introduction:
IT-ES308-IU-4F are a smart plug-and-play industrial
Ethernet switch, which can provide economical solution for your
Ethernet. Its dustproof fully sealed structure(protective case of
IP30 level), over-current, over-voltage and EMC protected
redundant double power input as well as built-in intelligent
alarm design can help system main tenancy personnel monitor
the network operation, which can work reliably in harsh and
dangerous environment.
IT-ES308-IU-4F supports 4 TP ports and 4 fiber ports
(IT-ES308-IU-4F: 4-ports 10/100Base-Tx, 4-ports 100Base-FX).
TP (RJ45) support 10/100Base-T(X), Full/Half duplex mode,
and auto MDI/MDI-X connection; 100BaseFX supports
single-/multi-mode, SC/ST/FC connector for optional.
Packing List:
The IT-ES308-IU-4F switch is shipped with following items.
1. Ethernet switch IT-ES308-IU-4F (plus terminal block) x1
2. Hardware Installation Guide x1
3. Product Warranty Statement x1
4. DIN-Rail setting fittings
IT-ES308-IU-4F
Hardware Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT-ES308-IU-4F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intellisystem IT-ES308-IU-4F

Summary of Contents for Intellisystem IT-ES308-IU-4F

  • Page 1 IT-ES308-IU-4F supports 4 TP ports and 4 fiber ports (IT-ES308-IU-4F: 4-ports 10/100Base-Tx, 4-ports 100Base-FX). TP (RJ45) support 10/100Base-T(X), Full/Half duplex mode, and auto MDI/MDI-X connection;...

  • Page 2: Panel Layout

    6. Redundant 24VDC power input (12V～48VDC) 7. Designed for industrial applications. IP30 protection, Rugged high-strength metal case Panel Layout: IT-ES308-IU-4F (4 TP ports and 4 fiber ports): Top panel Front panel 1. Grounding screw 2. Terminal block (4 bits) for PWR1/PWR2...

  • Page 3: Communication Connector

    11. Facility run indication LED 12. System alarm indication LED 13. Port indication LED 14. Power input PWR1 LED 15. Power input PWR2 LED Back panel Units（mm） Communication connector: IT-ES308-IU-4F have 4 10/100BaseT(X) Ethernet ports (RJ45) and 4 100BaseFX (SC/ST/FC type connector) fiber ports.
  • Page 4 10/100BaseT(X) Ethernet port The pin out of RJ45 port display as below, connect by UTP or STP. The connect distance is no more than 100m. 100Mbps is used 100Ωof UTP 5, 10Mbps is used 100Ωof UTP 3, 4, 5. RJ45 port support automatic MDI/MDI-X operation. Can connect the PC, Server, Converter and HUB .Pin 1,2,3,6 Corresponding connection in MDI.
  • Page 5 MDI-X (Cross-over cable) RJ45 (RX+) (TX+) (RX-) (TX-) (TX+) (RX+) (TX-) (RX-) 100BaseFX port 100Base-FX full-duplex SM or MM port, SC/ST/FC type .The fiber port must be used in pair, TX (transmit) port connect remote switch’s RX (receive) port; RX (receive) port connect remote switch’s TX (transmit) port.

  • Page 6: Led Indicator

    LED Indicator: LED indictor light on the front panel of IT-ES308-IU-4F .the function of each LED is described in the table as below. System indication LED State Description Power1 is being supplied to PWR1 Power1 is not being supplied Power2 is being supplied to...

  • Page 7: Power Input

    IT-ES308-IU-4F to support a relay alarm output, external warning light or alarm buzzer, also can add other digital acquisition device so that in the event of an alarm to alert the operator when a timely manner.

  • Page 8: Installation

    Relative humidity 10% to 95% DIN-Rail Installation In order to use in industrial environments expediently, IT-ES308-IU-4F adopt 35mm DIN-Rail installation, the installation steps as follows: 1. Examine the DIN-Rail attachment 2. Examine DIN Rail whether be firm and the position be suitability or not.

  • Page 9: Wiring Requirements

    Wiring Requirements： Be sure to disconnect the power cord before installing and/or wiring your Ethernet Switch. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size. If the current goes above the maximum ratings, the wiring could overheat may causing serious damage to your equipment.

  • Page 10: Specifications

    that you label wiring to all devices in the system when necessary. Specifications: Interfaces RJ45 Ports: 10/100BaseT(X) auto connection, F /H duplex or force work mode, and support MDI/MDI-X connection Fiber Ports: 100BaseFX ports (SC/ST/FC connector, optional) Single-mode: 20, 40, 60, 80, 100,120Km, optional Multi-mode: 2Km, optional Wavelength: 850nm, 1310 nm, 1550nm Alarm output interface：One relay alarm output.
  • Page 11 Environmental Operating Temperature: -40 to 75°C Storage Temperature: -45 to 85 °C Ambient Relative Humidity: 10% to 95% (non-condensing) Approvals EMI：FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), Level 4 EN61000-4-3 (RS)，Level 3 EN61000-4-4 (EFT)，Level 4 EN61000-4-5 (Surge)，Level 4 EN61000-4-6 (CS)，Level 4 EN61000-4-8，Level 5 Shock: IEC 60068-2-27...
