- Page 1 IT-ES5024-IM Series Managed Industrial Ethernet Switch User Manual...
-
Page 2: Packing List
【Summarize】 IT-ES5024-IM series is an industrial grade and managed industrial Ethernet switch. The IT-ES5024-IM-P (100/240VAC) industrial Ethernet switches consists Ethernet ports. IT-ES5024-IM-2F-P (100/240VAC) industrial Ethernet switches consists of 22 Ethernet ports and 2 Fiber ports. The IT-ES5024-IM-4F-P (100/240VAC) industrial Ethernet switches consists of 20 Ethernet ports and 4 Fiber ports. - Page 3 Certificate of quality ⅹ 1 Warranty card ⅹ 1 Please inform us or our distributor if your equipments have been damaged or lost any accessories, we will try our best to satisfy you. 【Features】 High performance network exchange technology Support IEEE802.3, IEEE802.3u, IEEE 802.3x IEEE802.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W Support 8K MAC address Support 12.8Gbps backboard bandwidth...
-
Page 4: Panel Layout
【Panel layout】 IT-ES5024-IM-P (100/240VAC) Front panel Rear panel Restore factory settings Console port Link/ACT LEDs Systems running LED The power LED Relay alarm LED Hangers Power input and Relay output terminal block 10/100BaseT(X) (RJ45) ports Rear panel connector LEDs IT-ES5024-IM-2F-P (100/240VAC) Front panel Rear panel Restore factory settings... - Page 5 Console port Link/ACT LEDs Systems running LED The power LED Relay alarm LED Hangers Power input and Relay output terminal block 10/100BaseT(X) (RJ45) ports 100Base-FX ports Rear panel connector LEDs IT-ES5024-IM-4F-P (100/240VAC) Front panel Rear panel Restore factory settings Console port Link/ACT LEDs Systems running LED The power LED...
- Page 6 IT-ES5024-IM-8F-P (100/240VAC) Front panel Rear panel Restore factory settings Console port Link/ACT LEDs Systems running LED The power LED Relay alarm LED Hangers Power input and Relay output terminal block 10/100BaseT(X) (RJ45) ports 100Base-FX ports Rear panel connector LEDs IT-ES5024-IM-12F-P (100/240VAC) Front panel Rear panel Restore factory settings...
- Page 7 Systems running LED The power LED Relay alarm LED Hangers Power input and Relay output terminal block 10/100BaseT(X) (RJ45) ports 100Base-FX ports Rear panel connector LEDs IT-ES5024-IM-16F-P (100/240VAC) Front panel Rear panel Restore factory settings Console port Link/ACT LEDs Systems running LED The power LED Relay alarm LED Hangers...
- Page 8 IT-ES5024-IM-20F-P (100/240VAC) Front panel Rear panel 1. Restore factory settings 2. Console port 3. Link/ACT LEDs 4. Systems running LED 5. Relay alarm LED 6. The power LED 7. Power input and Relay output terminal block 8. 10/100BaseT(X) (RJ45) ports 9.
-
Page 9: Power Supply Input
1. Restore factory settings 2. Console port 3. Link/ACT LEDs 4. Systems running LED 5. Relay alarm LED 6. The power LED 7. Power input and Relay output terminal block 8. 100Base-FX ports 9. Rear panel connector LEDs 【Power supply input】 The series rear panel provides 3 bit wiring terminal for AC100~240V power entered. -
Page 10: Appearance And Dimensions
【Appearance and dimensions】 This series of dimensions length width height, between product series port number is different. Unit（mm） 【Relay connection】 Relay access terminals in the rear panel of the device, next to the power input parts, R+ and R- are in the middle of the relay... -
Page 11: Communication Connector
alarm output section. It is used to detect both power failure and port failure. The open circuit state in normal non alarm state, when there is any alarm information to the closed state. This series of single power supply device is 1 relay alarm output, external alarm lights or alarm buzzer or external switch signal acquisition device in order to timely notify operators when an alarm occurs. - Page 12 MDI (straight-through cable) MDI-X (Cross-over cable) MDI/MDI-X auto connection makes switch easy to use for customers without considering the type of network cable. 100Base-FX Fiber port 100Base-FX full-duplex SM or MM port, SC/ST/FC type .The fiber port must be used in pair, TX (transmit) port connect remote switch’s RX (receive) port;...
-
Page 13: Led Indicators
【LED Indicators】 LED indicator light on the front panel of product, the function of each LED is described in the table as below. System Indication LED State Description Power is being supplied to power input PWR input Power is not being supplied to power input PWR input ON/OFF System is not running well... - Page 14 Whether it is close to the connection equipment and other equipment are prepared or not. 1. Avoid in the sunshine, keep away from the heat fountainhead or the area where in intense EMI. 2. Examine the cables and plugs that installation requirements. 3.
-
Page 15: Specifications
length depends on actual position; 4. All the cable cannot have break-down and terminal in the middle; 5. Cables should be straight in the hallways and turning; 6. Cable should be straight in the groove, and cannot beyond the groove in case of holding back the inlet and outlet holes. Cables should be banded and fixed when they are out of the groove;... - Page 16 Functions: Switch function: SW-Ring, QOS, 802.1QVLAN, RSTP, SNMP, Port trunking, static multicast filter, port mirroring, bandwidth management, broadcast storm control, port flow statistics, upgrade online, up and download configuration file, user name access system SW-Ring: Support Single, Couple, Chain, Dual homing Exchange attributes: 100M forward speed: 148810pps 100M maximum filter speed: 148810pps...
- Page 17 LED indicators: Run indicator: Run Interface indicator: Link (1~24) Power supply indicator: PWR Alarm indicator: Alarm Power supply: Input voltage: 100～240VAC Type of input：3 bit terminal block Overload Current Protection：1.2A Consumption: IT-ES5024-IM-P (100/240VDC): Unload consumption: 7.4W Full load consumption: 10.1W IT-ES5024-IM-2F-P (100/240VDC): Unload consumption: 8.7W Full load consumption: 11.4W...
- Page 18 IT-ES5024-IM-20F-P (100/240VDC): Unload consumption: 19.4W Full load consumption: 20.4W IT-ES5024-IM-24F-P (100/240VAC): Unload consumption: 22.0W Full load consumption: 23.0W Working environment: Working temperature: -40～75℃ Storage temperature:-40～85℃ Relative Humidity: 5%~95% (no condensation) Mechanical Structure: Shell: IP30 protect grade, metal shell Installation: 19” 1U rack Size（W×H×D）: 441.6mm×45mm×208.9mm Industry Standards: EMI: FCC Part 15, CISPR (EN55022) class A...
