Intellisystem IT-ES3016-IU Series User Manual

Intellisystem IT-ES3016-IU Series User Manual

Industrial ethernet switch

Advertisement

Quick Links

【Summarize】
IT-ES3016-IU series is a Plug-and-play unmanaged industrial Ethernet switch. The IT-ES3016-IU-P (12-48VDC) industrial Ethernet
switches consists of 16 Ethernet ports. The IT-ES3016-IU-2F-P (12-48VDC) consists of 14 Ethernet ports and 2 Fiber ports. The
IT-ES3016-IU-4F-P (12-48VDC) consists of 12 Ethernet ports and 4 Fiber ports. The IT-ES3016-IU-6F-P (12-48VDC) consists of 10
Ethernet ports and 6 Fiber ports. The IT-ES3016-IU-8F-P (12-48VDC) consists of 8 Ethernet ports and 8 Fiber ports that provide an
economical solution for your industrial Ethernet connection.
Product accorded to CE, FCC standard and Industry grade 4 design requirement, support 2 redundant power input and -40~
75℃ working temperature, can meet all kinds of Industrial environment requirement. It can use in power, water conservancy,
transportation area etc.
【Packing list】
Please check the packaging and accessories by your first using.
Industrial Ethernet switch ⅹ 1
User manual ⅹ 1
Certificate of quality ⅹ 1
Warranty card ⅹ 1
Please inform us or our distributor if your equipments have been damaged or lost any accessories, we will try our best to satisfy
you.
【Features】
Support IEEE802.3, IEEE802.3u, IEEE 802.3x
Support MAC address auto-learning, auto-aging
Support 8K MAC address
Support 12.8Gbps backboard bandwidth
Support redundancy power supply(12~48VDC),
Designed without fan
-40~75℃ work temperature
IP30 protection grade
DIN rail mount
IT-ES3016-IU Series
Industrial Ethernet Switch
User manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT-ES3016-IU Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intellisystem IT-ES3016-IU Series

  • Page 1 User manual 【Summarize】 IT-ES3016-IU series is a Plug-and-play unmanaged industrial Ethernet switch. The IT-ES3016-IU-P (12-48VDC) industrial Ethernet switches consists of 16 Ethernet ports. The IT-ES3016-IU-2F-P (12-48VDC) consists of 14 Ethernet ports and 2 Fiber ports. The IT-ES3016-IU-4F-P (12-48VDC) consists of 12 Ethernet ports and 4 Fiber ports. The IT-ES3016-IU-6F-P (12-48VDC) consists of 10 Ethernet ports and 6 Fiber ports.
  • Page 2: Panel Layout

    【Panel layout】 IT-ES3016-IU series Rear view Top view and below view IT-ES3016-IU-P (12-48VDC) Systems running LED The power LED Relay alarm LED (Retain) Link/ACT LEDs 10/100BaseT(X) (RJ45) ports Power input terminal block Ground screw Relay output terminal block(Retain) 10. Console port (Retain) 11.
  • Page 3 IT-ES3016-IU-2F-P (12-48VDC) Systems running LED The power LED Relay alarm LED Link/ACT LEDs 10/100BaseT(X) (RJ45) ports 100Base-FX ports Power input terminal block Ground screw Relay output terminal block 10. Console port 11. DIP switch 12. DIN-Rail mount IT-ES3016-IU-4F-P (12-48VDC) Systems running LED The power LED Relay alarm LED Link/ACT LEDs...
  • Page 4: Power Supply Input

    IT-ES3016-IU-6F-P (12-48VDC) Systems running LED The power LED Relay alarm LED Link/ACT LEDs 10/100BaseT(X) (RJ45) ports 100Base-FX ports Power input terminal block Ground screw Relay output terminal block 10. Console port 11. DIP switch 12. DIN-Rail mount IT-ES3016-IU-8F-P (12-48VDC) Systems running LED The power LED Relay alarm LED Link/ACT LEDs...
  • Page 5: Appearance And Dimensions

    IT-ES3016-IU series front panel provided 4 bit power supply input terminal block, support DC input. DC power supply input supported redundancy function, provided PWR1 and PWR2 power input, can use for single, and can connect 2 separately power supply system, use 1 pair terminal block connect the device at the same time. If one of the power systems broke, the device can work un-interruptible.
  • Page 6 MDI-X signal signal — — 4, 5, 7, 8 Note:“TX±”Transmit Data±,“RX±”Receive Data±,“—”Not Use. MDI (straight-through cable) MDI-X (Cross over cable) MDI/MDI-X auto connection makes switch easy to use for customers without considering the type of network cable. 100Base-FX Fiber port 100Base-FX full-duplex SM or MM port, SC/ST/FC type .The fiber port must be used in pair, TX (transmit) port connect remote switch’s RX (receive) port;...
  • Page 7: Led Indicators

    【LED Indicators】 LED indictor light on the front panel of product, the function of each LED is described in the table as below. System Indication LED State Description Power is being supplied to power input PWR input Power is not being (P1, P2) supplied to power input PWR input...
  • Page 8: Specifications

    Wiring Requirements Cable laying need to meet the following requirements, 1. It is needed to check whether the type, quantity and specification of cable match the requirement before cable laying; 2. It is needed to check the cable is damaged or not, factory records and quality assurance booklet before cable laying; 3.
  • Page 9 Transfer distance: Twisted cable: 100M(standard CAT5/CAT5e cable) Multi-mode: 1310nm, 2/5Km Single-mode: 1310nm, 20/40/60Km 1550nm, 80/100/120Km LED indicators: Run indicator: Run Interface indicator: Link (1~16) Power supply indicator: PWR (P1, P2) Alarm indicator: Alarm (Retain) Power supply Input voltage: 12~48VDC Type of input: 4 bit terminal block Overload Current Protection: 1.2A Support DC dual power supply redundancy Consumption...
  • Page 10 Industry Standards: EMI: FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2 (ESD), Level 4 EN61000-4-3 (RS), Level 3 EN61000-4-4 (EFT), Level 4 EN61000-4-5 (Surge), Level 4 EN61000-4-6 (CS), Level 3 EN61000-4-8, Level 5 Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6 Certifications CE, FCC, RoHS, PAL, UL508 (Pending)
