IT-ES2010-IU-2GS-4F
Unmanaged Industrial Ethernet Switch
【Introduction】
IT-ES2010-IU-2GS-4F is a type of plug-and-play industrial
unmanaged redundant Ethernet switch, which supports 4
10/100M ports, 4 optic fiber 100M ports(SC/ST) and 2 gigabit
Ethernet ports (SFP slots). No fan, low consumption and
industrial grade design. More steadily work capability. To satisfy
applications
IT-ES2010-IU-2GS-4F can also provide wide temperature type
in accommodation with limit temperature (-40 ~ 75°C) and we
have got CE, FCC approvals
【Packing List】
The IT-ES2010-IU-2GS-4F series switch is shipped with
following items.
IT-ES2010-IU-2GS-4F Ethernet switch(Plus Terminal Block)
x 1
Hardware Installation Guide ×1
DIN-Rail setting fittings(wall mounting for optional)
【Features】
Support IEEE802.3、IEEE802.3u、IEEE802.3x、
IEEE802.3z
Plug-and-play, MDI/MDI-X auto connection
Store and forward
Hardware Installation Guide
in
different
industrial
environments,
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Intellisystem IT-ES2010-IU-2GS-4F Series
Summary of Contents for Intellisystem IT-ES2010-IU-2GS-4F Series
- Page 1 IT-ES2010-IU-2GS-4F can also provide wide temperature type in accommodation with limit temperature (-40 ~ 75°C) and we have got CE, FCC approvals 【Packing List】 The IT-ES2010-IU-2GS-4F series switch is shipped with following items. IT-ES2010-IU-2GS-4F Ethernet switch(Plus Terminal Block) Hardware Installation Guide ×1 DIN-Rail setting fittings(wall mounting for optional) 【Features】...
-
Page 2: Panel Layout
Support broadcast storm shield LED light indicates the status of network 12～48VDC dual power supply -25～70℃ operating temperature range Industrial grade design, IP30 protection, metal shell. 【Panel Layout】 IT-ES2010-IU-2GS-4F： Power input (top panel) Front Panel Top panel... -
Page 3: Communication Connector
Unit（mm） 【Communication Connector】 IT-ES2010-IU-2GS-4F industrial Ethernet switch provides 4 10/100BaseT(X) Ethernet ports（RJ45）, 4 100Base-FX fiber ports（SC/ST optional）2 gigabit SFP fiber ports。 10/100BaseT(X) Ethernet port The pinout of RJ45 port display as below, connect by UTP or STP. The connect distance is no more than 100m. 100Mbps is used 100Ωof UTP 5, 10Mbps is used 100Ωof UTP 3,4,5. - Page 4 RJ 45 port support automatic MDI/MDI-X operation. Can connect the PC, Server, Converter and HUB .Pin 1,2,3,6 Corresponding connection in MDI. 1→3, 2→6, 3→1, 6→2 are used as cross wiring in the MDI-X port of Converter and HUB. 10Base-T/100Base-TX are used in MDI/MDI-X, the define of Pin in the table as below.
-
Page 5: Led Indicator
100BaseFX port 100Base-FX full-duplex SM or MM port, SC/ST type .The fiber port must be used in pair, TX (transmit) port connect remote switch’s RX (receive) port; RX (receive) port connect remote switch’s TX (transmit) port. The optical fiber connection supports the line to instruct enhance the reliability of network effectively Suppose: If you make your own cable, we suggest labeling the two sides of the same line with the same letter (A-to-A and... -
Page 6: Power Input
Power is not being supplied to power input PWR input FX port is active FX port is inactive Link （green） Blinkin Data is being transmitted Each RJ45 has two LED indicator 100M work mode （100Base-TX） 10M/100M （green） 10M work mode （10Base-T）... -
Page 7: Installation
Relative humidity 10% to 95% DIN Rail Installation In order to use in industrial environments expediently, IT-ES2010-IU-2GS-4F series adopt 35mm DIN-Rail installation, the installation steps as below, 1. Examine the DIN-Rail attachment 2. Examine DIN Rail whether be firm and the position be suitability or not. -
Page 8: Specifications
3. The required cable specification, quantity, direction and laying position need to match construction requirements, and cable length depends on actual position; 4. All the cable cannot have break-down and terminal in the middle; 5. Cables should be straight in the hallways and turning; 6. - Page 9 Fiber port：100BaseFX ports (SC/ST connector, optional) Single-mode: 20, 40, 60, 80, 100,120Km, optional Multi-mode: 2Km, optional. 1000BaseSX/LX/LHX/ZX (LC connector) Wavelength: 850nm, 1310 nm, 1550nm Power 24VDC power input（12～48VDC） Consumption is less than 8.1W Overload Current Protection Mechanical Shell：IP30 protection, metal case Installation：Wall or DIN Rail Mounting Dimensions（L*H*D）...
- Page 10 【Certifications】...
