  • Page 1 IT-ES5024-IM Series Managed Industrial Ethernet Switch CLI User Manual...
  • Page 2 CLI User Manual IT-ES5024-IM Series User Manual Statement Copyright Notice Information in this document is reserved by Intellisystem Technologies. Reproduction and extract without permission is prohibited. Agreement As the product version upgrades or other reasons, this document is subject to change without notice.

  • Page 3: Table Of Contents

    CLI User Manual Content CHAPTER 1 LOGIN ETHERNET SWITCH ........................1 ........................1 1.1 C ONFIGURATION THROUGH CONSOLE PORT ..........................3 1.2 C ONFIGURATION THROUGH ELNET .................................. 5 1.3 A GREEMENT ..............................5 1.4 C OMMAND LINE PORT 1.4. 1 View o f Co mma nd Li nes ..........................5 1.4.2 Command lines Online help ..........................
  • Page 4 CLI User Manual CHAPTER 7 MULTICAST FILTERING VIEW ......................23 ......................... 23 7.1 E NTER THE MULTICAST FILTERING VIEW ......................... 23 7.2 C ONFIGURE MULTICAST FILTERING TYPE ..........................23 7.3 IG MP LIST EN AN D C HEC K ......................... 24 7.4 D IG MP ISP LAY...
  • Page 5 CLI User Manual ......................37 14.2 P ORT MIRRORING CONFIGURATION DELETE ......................37 14.3 D ISPLAY PORT MIRRORING INFORMATION CHAPTER 15 TIME CONFIGURATION ........................38 ........................38 15.1 I N VIEW OF THE IME CONFIGURATION ...................... 38 15.2 T HE ALLOCATION OF TIME ALLOCATION VIEW CHAPTER 16 STATIC MULTICAST CONFIGURATION..................

  • Page 6: Chapter 1 Login Ethernet Switch

    Console port of the Ethernet switch. (Figure 1.1.1) This cable is used for connecting the IT-ES5024-IM series switch Console port and the external monitoring terminal equipment. One end is RJ45 eight core plug, the other end is the 9 hole plug (DB9).
  • Page 7 CLI User Manual (Figure 1.1.3) 2) Choose connecting serial port. Choose connecting serial port under “Connect using”（pay attention to the chosen serial port is consistent with the port connected with the configuration cable） ，Click “OK”. As shown in Figure 1.1.4. (Figure 1.1.4) 3) Set serial port parameters.

  • Page 8: Configuration Through Telnet

    Terminal device use telnet connect to IT-ES5024-IM series through PC, the requirements are as follows: 1. The IP address of IT-ES5024-IM series can get it by search or modify (Use IP command under the system management view); 2. If PC and IT-ES5024-IM in the same local area network, the IP address must in a same network...
  • Page 9 CLI User Manual segment, otherwise, PC and IT-ES5024-IM must cross-router. If satisfied these two requirements, can use telnet access to IT-ES5024-IM series, and then configure the IT-ES5024-IM. 1）Establish configuration environment, just connect PC’s Ethernet port connect to IT-ES5024-IM’s Ethernet port through Local area network.

  • Page 10: Agreement

    1.4.1 View of Command Lines IT-ES5024-IM series’ view of command lines aim at configuration of different functions. First of all, IT-ES5024-IM series establish connection, then confirmation of user name and password finished, after enter the correct user name and password, enter “help or ?”...
  • Page 11 CLI User Manual command, figure 1.4.1 as follows: (Figure 1.4.1) Table 1.4.1 system view command list...
  • Page 12 CLI User Manual View Function DOS Prompt Enter Quit Quit and System View Switch# return to user login Show or modify device Switch Information information, like software Information (information)# version, IP address, etc. Show or modify the port information, such as: duplex Port Port Settings Switch (Port)#...

  • Page 13: Command Lines Online Help

    CLI User Manual View or modify the static unicast MAC address and Switch (Access)# Access MAC port lock port SNMP SNMP enable configuration Switch(Snmp)# Snmp Configuration View or modify the message alarm information, such as Switch (Email)# Email Email Warning mail server address,...
  • Page 14 CLI User Manual Bandwidth --Enter bandwidth management menu MultiFilter --Enter multicast filtering menu Multicast --Enter static multicast filters menu Vlan --Enter vlan menu --Enter QoS menu Ring --Enter Ring menu Trunk --Enter Trunking setting menu Snmp -- Enter Snmp setting menu Alarm --Enter alarm setting menu Statistics...

  • Page 15: Frequent Incorrect Information Of Command Lines

    CLI User Manual 1.4.3 Frequent Incorrect Information of Command Lines All commands typed by users, if it is certificated by grammar, it can run correctly, or users will be sent incorrect information. Frequent incorrect information is in table 1.4.3 as below: Table 1.4.3 frequent incorrect information English incorrect information Reason...

  • Page 16: Chapter 2 Device System Based Information Configuration

    CLI User Manual CHAPTER 2 Device system based information configuration Device information includes Device Type, Hardware Version, Device Name, Software Version, Device Description, Device SN and Contact Way. Among them, Hardware Version and Software Version can be only read, not modified. 2.1 Enter into the view of device information Please check the view as figure 2.1.1 Table 2.1.1...

  • Page 17: Configuration Information

    CLI User Manual Switch(information)# show others Device type Managed Switch Device name Industrial Switch Description 24PORT Serial number Contact way Example: Check the MAC address Switch(information)# show mac Device MAC address: 00.22.6F.02.B0.83 2.3 Configuration information Please reference user configuration device information as table 2.3.1: Table 2.3.1 Operating Command...

  • Page 18: Delete Device Information

    CLI User Manual 2.4 Delete device information Please reference table 2.4.1 Table 2.4.1 Operating Command Description Clean –t Delete Device Type Carry our under the view of device information Delete Device Name Clean -n Carry our under the view of device information Delete Serial Number Carry our under the view of device information Clean -m...

  • Page 19: Chapter 3 Port Configuration

    10Mbps, 100Mbps), interface type (electric or optical), flow control, port is enabled. 3.1 Port information The Ethernet port characteristics of IT-ES5024-IM series switches support: 10/100Base-Tx Ethernet port can operate in half duplex, full duplex, auto negotiation mode. Support MDI/MDIX adaptive, and able to negotiate with other network devices, automatic selection of the most appropriate way of working and rate, which greatly simplifies the configuration and management system;...

  • Page 20: Configure The Port Speed And Duplex Mode

    CLI User Manual Table 3.3.1 Operating Command Description Enable port Enable <portlist> {enable|disable} <portlist>：1, 3, 5-24 or all Example: 3, 4, 6 closed port Switch（Port）# Enable 3,4,6 disable [OK] 3.5 Configure the port speed and duplex mode Table 3.4.1 configure the port speed and duplex. Table 3.4.1 Operating Command...

  • Page 21: Chapter 4 Bandwidth Management

    CLI User Manual Chapter 4 Bandwidth Management 4.1 Enter rate management view Bandwidth allocation including: 1. Entrance velocity distribution; 2. The outlet velocity distribution; 3. Check the entrance rate configuration information; 4. Check the export rate of configuration information; Table 4.1.1 in bandwidth management view: Operating Command Description...

  • Page 22: Ingress Bandwidth Configuration

    CLI User Manual 4.3 Ingress bandwidth configuration By default, Ingress bandwidth does not limit. Table 4.3.1 Ingress bandwidth configuration: Table 4.3.1 Operating Command Description <portlist>：1,3,5-24 or all <Bandwidth>：(64k, 128k, 256k, 512k, 1M, 2M, 3M, 4M, 5M, 6M, 7M, 8M, 9M, 10M, 20M, 30M, Ingress Config inrate<portlist>...

  • Page 23: Chapter 5 Broadcast Storm Set

    CLI User Manual Chapter 5 Broadcast Storm Set 5.1 Set the view into the broadcast storm The broadcast storm including： 1. Show broadcast storm set 2. Close broadcast storm inhibition 3. Set broadcast storm set Table 5.1.1 into the broadcast storm view command： Table 5.1.1 Operating Command...
  • Page 24 CLI User Manual Example: the configured limit packet type is only broadcast packets, the maximum rate of 5% Switch (Storm)#Config 1 5 Maximum rate：5% Limited type：Broadcast Only [OK]...

  • Page 25: Chapter 6 Vlan

    CLI User Manual Chapter 6 VLAN 6.1 Introduction to VLAN VLAN (Virtual Local Area Network) is a virtual local area network, is a kind of device by LAN logical rather than physical division into a network, in order to achieve the virtual group technology. VLAN technology allows network administrators to one physical LAN logic into different broadcast domains (or virtual LAN, VLAN), each VLAN contains a set of computer workstations have the same needs, have the same properties and physical form on LAN.

  • Page 26: Enter The Port Configuration View Based On Vlan

    CLI User Manual Example: Vlan type: 802.1Q Vlan Switch (VLAN) # enable 1 802.1Q VLAN is enable! [OK] Tip: This configuration will be validated after restarting 6.4 Enter the port configuration view based on Vlan Table 6.4.1 to enter the port configuration view based on vlan: Operating Command Description...
  • Page 27 CLI User Manual Operating Command Description View port PVID <portlist>: 1,3,5-24 or all Show pvid <portlist> To view the VLAN logo to replace the Show replace configuration View management Show manage Example: add type Vlan2 port 4 for U Switch（VLAN）# add 2 4 u [OK] Tip: This configuration will be validated after restarting Example: see VLAN 1 information...

  • Page 28: Chapter 7 Multicast Filtering View

    CLI User Manual Chapter 7 Multicast filtering view 7.1 Enter the multicast filtering view Multicast filtering configuration includes: 1. types of configuration, multicast filtering 2. listen to the IGMP 3. the IGMP query 4. the IGMP query interval configuration 5. display the IGMP sensing information 6.

  • Page 29: Display Igmp Information

    CLI User Manual Switch (Multicast)#Config query 60 7.4 Display IGMP information Table 7.4.1 shows the IGMP information: Operating Command Description Display IGMP information Show IGMP 7.5 The GMRP configuration Table 6.5.1GMRP configuration: Operating Command Description Enable Configure the GMRP enable Set GMRP {enable|disable} disable Configure the GMRP port...

  • Page 30: Chapter 8 Qos

    CLI User Manual Chapter 8 QoS 8.1 Enter the multicast filtering view The QoS configuration including: 1. Enable Dscp, Cos 2. Set Qos (8:4:2:1 high priority queue mechanism, strict priority) 3. The value of Cos/Dscp mapping 4. The default port priority 5.

  • Page 31: The Value Of Dscp/Tos Mapping

    CLI User Manual 8.4 The value of Dscp/Tos mapping The user can use the follow ing command to configure the Dscp/cos value map Table 8.4.1 Dscp/cos mapping configuration command: Operating Command Description <coslist>：CoS Mapping value，0，1，2- Config <coslist> The value of Cos mapping <classlist>：The priority queue，...
  • Page 32 CLI User Manual Operating Command Description <dscplist>：Dscp Mapping value，1，2， To view the ToS value map Show Dscp <dscplist> 3-64 To view the ToS/CoS enabled state Show state <portlist> <portlist>：port 1，2，3-24 To view the default port priority Show default <portlist> <portlist>：port 1，2，3-24...

  • Page 33: Chapter 9 Ring Configuration

    CLI User Manual Chapter 9 Ring configuration 9.1 Enter the ring network configuration view The ring network configuration including: 1. The Ring3 configuration; 2. Ring network information view ; 3. The RSTP configuration 4. RSTP state information view Table 9.1.1 into the ring network configuration view: Operating Command Description...

  • Page 34: The Ring3 Configuration

    CLI User Manual 9.4 The Ring3 configuration Ring3 enabled, can use the follow ing command to set the Ring3. Table 9.4.1 Ring3 to set and modify: Operating Command Description {1|2|3|4 } ： 1 ring group 1, 2 ring group 2 3 ring group 3, 4 ring group 4 <id>...

  • Page 35: Ring Network Configuration Information

    CLI User Manual Example: to modify the first groups in SWRing3 ring network ports 5, 6 Switch(Ring)# modify 1 -p 5,6 [OK] Tip: This configuration will be validated after restarting 9.5 Ring network configuration information Allocation of ring network, we can use the following command to view the ring network configuration information.

  • Page 36: Display The Current State Of The Rstp Information

    CLI User Manual Example: RSTP port configuration Switch(Ring)# Modify rstp_p 1 20000 224 yes 1 1 9.7 Display the current state of the Rstp information The configuration of Rstp, can use the following command to view the Rstp current status information. Table 9.7.1 view the Rstp information about the current configuration command: Operating Command...

  • Page 37: Chapter 10 Trunk Configuration

    CLI User Manual Chapter 10 Trunk configuration 10.1 Enter the port Trunk view Port Trunk configuration includes: 1. Port trunk configuration; 2. Delete port information fusion; 3. Port trunk information view; Table 10.1.1 to enter the port trunk view: Operating Command Description Enter the port trunk configuration view...

  • Page 38: Chapter 11 Mac Port Lock

    CLI User Manual Chapter 11 MAC port lock 11.1 Enter the MAC port lock view MAC port lock includes; 1. MAC port locking information display 2. Add the MAC port locking information 3. Remove the MAC port locking information Table 11.1.1 into the MAC port to lock the view command: Operating Command Description...

  • Page 39: Chapter 12 Email Alarm Configuration

    CLI User Manual Chapter 12 Email alarm configuration 12.1 Enter the Email alarm view Email alert configuration including: 1. Displays the Email alarm information 2. Email alarm enable 3. To configure the mail server address 4. The allocation of the recipient's address 5.

  • Page 40: Chapter 13 Alarm Configuration

    CLI User Manual Chapter 13 Alarm configuration 13.1 Enter the alarm information view Alarm configuration including: 1. Power alarm; 2. Port alarm; 3. Delete alarm information; 4. Alarm information view; Table 13.1.1 enter the alarm configuration view: Operating Command Description Enter the alarm configuration view Alarm To perform the operation in the system...
  • Page 41 CLI User Manual Operating Command Description {1|2|all}：Show the way power alarm Show power alarm Show power {1|2|all} 1： The first power supply； information 2： The second way power Show port alarm Show port <portlist> <portlist>：Alarm ports 1，2，3-24 or all information Example: set the alarm information port Switch（Alarm）# show port all Port:1...

  • Page 42: Chapter 14 Port Mirroring

    CLI User Manual Chapter 14 Port mirroring 14.1 Enter the port mirroring view Port mirroring configuration includes: 1. Port mirroring configuration; 2. Delete port mirroring; 3. View port mirroring; Table 14.1.1 to enter the port mirroring configuration view: Operating Command Description Enter the port mirroring configuration view To perform the operation in the system...

  • Page 43: Chapter 15 Time Configuration

    CLI User Manual Chapter 15 Time configuration 15.1 In view of the Time configuration Time allocation: 1. Time display configuration information 2. Time to enable 3. The world time zone selection 4. The address of the NTP server Table 15.1.1 into the time allocation view Operating Command Description...

  • Page 44: Chapter 16 Static Multicast Configuration

    CLI User Manual Chapter 16 Static multicast configuration 16.1 In the static multicast address filter configuration view Static multicast configuration includes: 1. Add static multicast address; 2. Remove the multicast address; 3. To view the multicast address; Table 16.1.1 into the static multicast view command: Operating Command Description...

  • Page 45: Chapter 17 The Snmp Configuration

    CLI User Manual Chapter 17 The SNMP configuration 17.1 Configure the view into the SNMP The Snmp configuration including: 1. Close the Snmp 2. To view the Snmp configuration information 3. The Snmp configuration Table 17.1.1 to enter the Snmp configuration view: Operating Command Description...

  • Page 46: Chapter 18 Port Statistics

    CLI User Manual Chapter 18 Port Statistics 18.1 Enter the port statistical configuration view Port statistics: 1. Statistics port number and type 2. Clean up the count the number of frames 3. Statistics port flow 4. Clean up the total flow 5.

  • Page 47: Chapter 19 System Management

    CLI User Manual Chapter 19 System management 19.1 Enter the System management configuration view System management includes: 1. System timeout; 2. The default gateway, IP address configuration; 3. The user name, password configuration; 4. Device IP, subnet mask, default gateway, see; 5.

  • Page 48: User Name, Password Settings

    CLI User Manual Operating Command Description The device IP address <A.B.C.D>：ip address Ip <A.B.C.D> <A1.B1.C1.D1> configuration <A1.B1.C1.D1>：The subnet mask The default gateway Gateway <A.B.C.D> <A.B.C.D>：The gateway address configuration Example: the equipment configuration for 192.168.254 IP 255.255.255.0, subnet mask, default gateway for 192.168.1.1 Switch(Manage)# ip 192.168.1.254 255.255.255.0 [OK]...

  • Page 49: Restore Factory Settings

    CLI User Manual 19.6 Restore factory settings The user can restore to factory settings following command equipment Table 19.6.1 restores factory settings command: Operating Command Description Restore the device to To perform the operation in the system manage Restore factory settings Example: To restore the device to factory settings Switch（manage）# restore Restore Settings or not ? (yes/no) yes...

  • Page 50: The System Upgrade

    CLI User Manual 2. Super terminal and choose to upload the configuration file, the suffix.Cfg [transfer] →[Send the file] →[browse] →[Select the folder] →[Users to upload the configuration file] → [OPEN] → [Use receiving protocol] →[Xmodem]→[Send] 19.8 The system upgrade Through the super terminal, users can upgrade the following command file system (Before the upgrade, please confirm the correctness of the file) Table 19.8.1 system upgrade.
