8-ports Unmanaged Industrial Ethernet Switch
Introduction:
IT-ES308-IU-2F are a smart plug-and-play industrial
Ethernet switch, which can provide economical solution for your
Ethernet. Its dustproof fully sealed structure(protective case of IP30
level), over-current, over-voltage and EMC protected redundant
double power input as well as built-in intelligent alarm design can
help system main tenancy personnel monitor the network operation,
which can work reliably in harsh and dangerous environment.
IT-ES308-IU-2F supports 6 TP ports and 2 fiber ports
(IT-ES308-IU-2F: 6-port 10/100Base-Tx, 2-port 100Base-FX). TP
(RJ45) support 10/100Base-T(X), Full/Half duplex mode, and auto
MDI/MDI-X connection; 100BaseFX supports single-/multi-mode,
SC/ST/FC connector for optional.
Packing List:
The IT-ES308-IU-2F switch is shipped with following items.
1. Ethernet switch IT-ES308-IU-2F (plus terminal block) ×1
2. Hardware Installation Guide ×1
3. Product Warranty Statement ×1
4. DIN-Rail setting fittings ×1
IT-ES308-IU-2F
Hardware Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Intellisystem IT-ES308-IU-2F
Summary of Contents for Intellisystem IT-ES308-IU-2F
- Page 1 IT-ES308-IU-2F supports 6 TP ports and 2 fiber ports (IT-ES308-IU-2F: 6-port 10/100Base-Tx, 2-port 100Base-FX). TP (RJ45) support 10/100Base-T(X), Full/Half duplex mode, and auto MDI/MDI-X connection;...
-
Page 2: Panel Layout
6. Redundant 24VDC power input (12V～48VDC) 7. Designed for industrial applications. IP30 protection, rugged high-strength metal case Panel Layout: IT-ES308-IU-2F (6 TP ports and 2 fiber ports): Top panel Front panel 1. Grounding screw 2. Terminal block (4 bits) for PWR1/PWR2... -
Page 3: Communication Connector
10. System alarm indication LED 11. Power input PWR1 LED 12. Power input PWR2 LED 13. Port indication LED 14. 100Base-FX ports Back panel Units（mm） Communication connector: IT-ES308-IU-2F have 6 10/100BaseT(X) Ethernet ports (RJ45) and 2 100BaseFX (SC/ST/FC type connector) fiber ports. - Page 4 10/100BaseT(X) Ethernet port The pin out of RJ45 port display as below, connect by UTP or STP. The connect distance is no more than 100m. 100Mbps is used 100Ωof UTP 5, 10Mbps is used 100Ωof UTP 3, 4, 5. RJ45 port support automatic MDI/MDI-X operation. Can connect the PC, Server, Converter and HUB .Pin 1,2,3,6 Corresponding connection in MDI.
- Page 5 MDI-X (Cross-over cable) RJ45 (RX+) (TX+) (RX-) (TX-) (TX+) (RX+) (TX-) (RX-) 100BaseFX port 100Base-FX full-duplex SM or MM port, SC/ST/FC type .The fiber port must be used in pair, TX (transmit) port connect remote switch’s RX (receive) port; RX (receive) port connect remote switch’s TX (transmit) port.
-
Page 6: Led Indicator
LED Indicator: LED indictor light on the front panel of IT-ES308-IU-2F .the function of each LED is described in the table as below. System indication LED State Description Power1 is being supplied to PWR1 Power1 is not being supplied Power2 is being supplied to... -
Page 7: Relay Contact
The two wires attached to the Fault contacts form an open circuit when: (1) IT-ES308-IU-2F have lost power from one of the DC power inputs, One of the ports for which the corresponding Port alarm DIP Switch is set to ON is not properly connected. -
Page 8: Switch Settings
Storage Temperature: -45°C to 85°C Relative humidity 10% to 95% DIN-Rail Installation order industrial environments expediently, IT-ES308-IU-2F adopt 35mm DIN-Rail installation, the installation steps as follows: 1. Examine the DIN-Rail attachment 2. Examine DIN Rail whether be firm and the position be suitability... -
Page 9: Wiring Requirements
or not. 3. Insert the top of the DIN-Rail into the slot just below the stiff metal spring. 4. The DIN-Rail attachment unit will insert into place as shown below. Wiring Requirements： Be sure to disconnect the power cord before installing and/or wiring your Ethernet Switch. -
Page 10: Specifications
thumb is that wiring that shares similar electrical characteristics can be bundled together. 4. Keep input and output wiring separated. It is strongly advised that you label wiring to all devices in the system when necessary. Specifications: Interfaces RJ45 Ports: 10/100BaseT(X) auto connection, F /H duplex or force work mode, and support MDI/MDI-X connection Fiber Ports: 100BaseFX ports (SC/ST/FC connector, optional) Single-mode: 20, 40, 60, 80, 100,120Km, optional... - Page 11 Casing: IP30 protection, Metal case Installation: DIN-Rail Weight: 900g Environmental Operating Temperature: -40 to 75°C Storage Temperature: -45 to 85 °C Ambient Relative Humidity: 10% to 95% (non-condensing) Approvals EMI：FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2(ESD), EN61000-4-3(RS), EN61000-4-4(EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8,...
