【Summarize】
IT-ES2010-IU-2GS is a type of plug-and-play industrial unmanaged redundant Ethernet switch, which supports 8 10/100M ports, and 2 gigabit
Ethernet ports (SFP slots). No fan, low consumption and industrial grade design. More steadily work capability. To satisfy applications in different
industrial environments, IT-ES2010-IU-2GS can also provide wide temperature type in accommodation with limit temperature (-40 ~ 75°C) and we
have got CE, FCC approvals.
【Packing List】
The first time use this product, please check the packaging is intact or not and the attachment is complete or not at first.
IT-ES2010-IU-2GS x1
User manual x1
Certificate x1
Warranty card x1
DIN-rail kit
f you find that the device is damaged or any parts of it is missing during transportation, please notify the Company or the Company's distributor,
I
we will give you proper solution as soon as possible.
【Features】
1. Support 8 10/100M ports, and 2 gigabit Ethernet ports (SFP slots)
2. Support IEEE802.3/802.3u /802.3x
3. Support 10/100M, half/full duplex, MDI/MDI -X
4. Support broadcast storm shield
5. DC12～48V Power input
6. Support industrial grade 4 level
7. IP30 protection, metal shell, DIN Rail
IT-ES2010-IU-2GS
Unmanaged Industrial
Ethernet switch
user manual
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Intellisystem IT-ES2010-IU-2GS
Summary of Contents for Intellisystem IT-ES2010-IU-2GS
- Page 1 【Summarize】 IT-ES2010-IU-2GS is a type of plug-and-play industrial unmanaged redundant Ethernet switch, which supports 8 10/100M ports, and 2 gigabit Ethernet ports (SFP slots). No fan, low consumption and industrial grade design. More steadily work capability. To satisfy applications in different industrial environments, IT-ES2010-IU-2GS can also provide wide temperature type in accommodation with limit temperature (-40 ~ 75°C) and we...
- Page 2 Top view Front view IT-ES2010-IU-2GS-P(12/48VDC) top panel provided 4 bit industrial terminal block, power input is 24VDC(12~48VDC) , the sign of the terminal block is V1-, V1+, V2-, V2+, it is redundant power input, both of them are 12~48VDC IT-ES2010-IU-2GS-P(12/48VDC) DC power input had redundant function, provided PWR1 and PWR2 power input, can use for single, and...
- Page 3 2, Power OFF, please pluck the plug of the power supply and then strike the terminal block parts. 【Communication interfaces】 IT-ES2010-IU-2GS provide 8 port 10/100BaseT(X) Ethernet（RJ45） and 2 port gigabit SFP optic fiber. 10/100BaseT(X) Ethernet port 10/100BaseT(X) Ethernet port is in front panel of the device. The connector type is RJ45 and its pin definition is shown belo w. The pinout of RJ45 port display as below, connect by UTP or STP.
- Page 4 Suggestion: please make a sign for the optic fiber (Figure as follows: A-A, B-B）, easy to use 【LED indicator】 LED indicator in front panel of IT-ES2010-IU-2GS-P (12/48VDC) monitor working status, it is convenience to find the problem, the function of each LED is described in the table as below.
- Page 5 Relative humidity 10% to 95% DIN-Rail Installation In order to use in industrial environments expediently, IT-ES2010-IU-2GS adopt 35mm DIN-Rail installation, the installation steps as fellows: 1. Examine the DIN-Rail attachment 2. Examine DIN Rail whether be firm and the position be suitability or not.
- Page 6 Power: Input power: 24VDC (12～48VDC) Input type: 4 bits terminal block Over voltage protection Environmental Operating Temperature: -40 to 75°C Storage Temperature: -45°C to 85°C Relative Humidity: 10 to 95% (non-condensing) Mechanical Shell: IP30 protection, metal case Installation: DIN Rail mounting W×H×D: 136mm×52mm×105mm Weight: 800g Approvals:...
