Chapter 4: High Performance Features and Safety Precautions
10. Electrical Pass through Iris allows electrical cords and data cords
to pass through the back of hood without leaving a large hole for
contaminants to escape. The hood ships with solid plugs and the
iris plugs are included with the instruction manual for your
convenience.
11. Shipped fully assembled to eliminate the need for costly onsite
assembly. Accessories such as the exhaust transition connections,
work surfaces, airflow monitors and fluorescent light kits are easily
installed.
12. Accessory Exhaust Connections. The Protector Demonstration
Hoods feature two exhaust locations: One is located on the top of
the rear plenum and the other is located on the bottom of the rear
plenum. The bottom exhaust incorporates a tissue screen to
prevent debris from clogging the exhaust blower. Exhaust
transition connectors are available for either a 6" OD outside
exhaust or a 5" ID hose. All exhaust transition connectors are
illustrated in Chapters 2 and 3 and accessories listed in Chapter 7.
The lower 5" ID hose exhaust connection is used with the mobile
cart for connection to the FilterMate Portable Exhauster which rests
on the lower shelf.
13. Accessory Guardian™ Digital 1000 Airflow Monitor or
Guardian 500 Monitor continuously monitors airflow. An
audio/visual alarm alerts the user to low airflow conditions. The
Guardian™ 1000 Digital Airflow Monitor also displays a face
velocity value, provides an RS232 output, a night setback mode
and several auxiliary relay ports. See Chapter 7 for ordering
information. See Chapter 6 for details, installation and calibration.
14. Accessory Fluorescent Light Kits provide excellent illumination
with an auxiliary outlet plug for supplying power to auxiliary
equipment such as a balance or printer. See Chapter 7 for ordering
information.
15. Accessory Roof-Mounted Blower sized to provide adequate
airflow to Protector Demonstration Hoods when used with an
exhaust damper. See Chapters 2, 3 and 7.
16. Accessory FilterMate Portable Exhauster provides up to 280 cfm
for HEPA or Carbon filtration or up to 220 cfm for combination
HEPA/Carbon filtration when connected to the hood. See Chapters
2, 3 and 7.
17. Mobile Demonstration Hood includes FilterMate Portable
Exhauster, Demonstration Hood, work surface and mobile cart to
allow easy transport throughout the facility. See Figure 3-6. Mobile
cart can be ordered separately as shown in Chapter 7.
