Chapter 6: Maintaining Your Protector Demonstration Hood
CALIBRATION - CONFIGURATION MENU
DISPLAY UNITS
LOW AIR ALARM
"RED LED"
LOW AIR CUTOFF
WARNING AIR ALARM
WARNING AIR RESET
HIGH AIR ALARM
LOWER AIR SAMPLE FLUCTUATIONS
HIGHER AIR FLUCTUATIONS
LOWER / HIGHER AIR SAMPLE
DIFFERENCE
WARN TO ALARM AIR TIME
ALARM TO WARN AIR TIME
SHOW AIR FLOW
SHOW TIME LINE OFF = DISPLAYS BAR
GRAPH
AUDIBLE ALARM
SENSOR DIFFERENCE
SENSITIVITY
* (Suggested Air Alarm Settings) Refer to the chart on the previous pages
for a range of air velocity settings that may be used.
5. To complete the CAL CONFIG, be sure to enter "DONE". You
are returned to the Main Menu.
Replacement Latch Kits
To replace an entire latch on the enclosure, follow the instructions and
order the following:
4810300 Latch Kit, Small (Short 22.8"H units)
4810301 Latch Kit (Tall 32"H units)
Product Service 1-800-522-7658
"YELLOW LED"
SETTINGS
FPM
* 48 FPM (60 fpm Operating inflow)
* 64 FPM (80 fpm Operating inflow)
* 80 FPM (100 fpm Operating inflow)
OFF
* 51 FPM (60 fpm Operating inflow)
* 67 FPM (80 fpm Operating inflow)
* 83 FPM (100 fpm Operating inflow)
3 FPM
OFF
OFF
3%
3%
10 SECONDS
3 SECONDS
ON
OFF
ENABLED
2%
80%
35
