Appendix A: Replacement Parts

Item Qty. Part Number
1A 1 3906500
1B 1 3926500
2 1 3906801
3A 1 3906101
3B 1 3926101
4 1 3907601
5 2.3 Ft. 6913700
6A 1 3907500
6B 1 3907501
7A 1 1927403
7B 1 3906700
7C 1 6916500
7D 2 1893206
7E 1 6916501
7F 1 3925300
8A 1 3905201
8B 1 3925201
9A 1 3907400
9B 1 3907401
9C 2 1932401
9D 2 1912108
9E 2 1909217
10 1 3905601
11 1 3905301
12 1 3913100
13A 1 3912400
13B 1 3912401
13C 1 3912402
13D 1 3912403
14A 1 1934601
14B 1 1936800
15A 2 7868402
15B 2 1912108
15C 2 1889316
16A 2 3915400
16B 2 3915401
16C 4 1889912
17 1 1595619
18 1 1595621
19 1 3941900
46
Description
Glass, Side Short
Glass, Side Tall
Glass, Top 3'
Glass, Sash 3' Short
Glass, Sash 3' Tall
Foil, Sash 3'
Wiper, Sash
Stop, Right Sash
Stop, Left Sash
Spring, Compression Sash Latch
Latch Bracket
Latch Sash
Screw, #8-32 x .38 Phil, SS, Type F
Latch Sash Tall
Latch Bracket Tall
Sash Assembly 3', Short
Sash Assembly 3' Tall
Bracket, Air Foil Right
Bracket, Air Foil Left
Washer, Shoulder Plastic
Washer, .194 ID x .38 OD x .03 thick plastic
Cap Nut #10-24 SS
Air Foil 3'
Header 3'
Cover Plate, Exhaust (Top or Bottom)
Upper Exhaust Transition 5" Hose
Upper Exhaust Transition 6" Duct
Lower Exhaust Transition 5" Hose
Lower Exhaust Transition 6" Duct
Bushing, Heyco with Flex Shutter 1.50 dia.
Bushing, Heyco Closed 1.50 dia.
Spacer Bushing
Washer, .194 ID x .38 OD x .03 T. Plastic
Screw, #10-24 x 1.00 PH. (SS)
Side Air Foil, Short
Side Air Foil, Tall
Screw, 6-32 x .75 PH. Type F, Oval Head
Hole Plug, .500 dia. Gray
Hole Plug, 1.187 dia. Gray
Label, Protector Demonstration Hood
Product Service 1-800-522-7658
