- Page 1 User manual MANO 5 Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.
-
Page 3: Table Of Contents
Content I. General Information ................5 I.I General Information – valid for MANO5001 ........10 I.II General Information – valid for MANO5001LV......... 16 II. Safety instructions ................18 III. Instructions ..................20 1. Scope of supply ................. 20 2. Commissioning .................. 20 Battery installation .................. - Page 4 3. Operation ................... 26 Compositions .................... 26 Turning ON/OFF ..................29 Acoustic signals ..................30 Magnification .................... 30 Color modes ..................... 31 Brightness....................33 Contrast adjustment (artificial color mode)..........34 LED lighting ON/OFF ................34 Freeze image ................... 34 Memory ..................... 36 Energy saving mode.................
-
Page 5: General Information
Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO 5 is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes. - Page 6 For this reason it should be ensured that the system is not placed directly beside or on top of another system. If the set-up of this system in the proximity of medical, measuring devices cannot be avoided, the operator of these devices has to be informed that it is necessary to observe the performance of the system to control the conventional use of the system in the chosen set-up.
- Page 7 Product description MANO 5 is a system to magnify text and images with the following benefits: ● 5” LCD display (approx. 12.9 cm diagonal) with true color and up to 20 artificial color modes ● continuous magnification of approx. 4x to 20x ●...
- Page 8 Special advice for transport and storage For safety reasons, the unit must only be shipped in the original packing. The unit must be stored in dry and closed rooms in the original packing. The following conditions for transport and storage have to be respected: ●...
- Page 9 Disposal or transfer of the device This equipment may retain user settings and stored images if disposed of or transferred. Prior to disposing or transferring MANO 5, remove all personal content from the device, as described in „Reset to default factory...
-
Page 10: General Information - Valid For Mano5001
I.I General Information – valid for MANO5001 The order code of your device can be found on the type label on the device or on the packaging. Purpose This electronic magnifier with voice output is a medical device to assist with the reading and magnifying of printed text and pictures. - Page 11 Declaration of conformity, CE mark You can request a copy of the declaration of conformity in written form from Reinecker Vision GmbH, Sandwiesenstr. 19, 64665 Alsbach-Hähnlein or view it at www.reineckervision.de/en/eu-doc Evolution and lifetime of products The Medical Device Directive regulates by law that manufacturers of medical devices shall determine a period of safety operation of a product.
- Page 12 Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation. Safety advice The device has to be set up and operated in closed and dry rooms only.
- Page 13 OFF and the battery must be taken out. Please do not switch ON the device again. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Reinstatement, installation and maintenance This device may be technically repaired and reconditioned by Reinecker Vision GmbH only or by an authorized technician.
- Page 14 Environmentally friendly disposal (Directive 2012/19/EU) Within the EU the respective national implementations of the Directive 2012/19/EU for the sustainable re-use and proper recycling of electrical and electronic equipment applies. For countries outside the EU (e.g. Switzerland), the respective national implementations for the regulatory requirements for environmentally friendly disposal and recycling applies.
- Page 15 List of symbols used Manufacturer Country of manufacture Model number Catalogue number Serial number Caution Medical device Unique Device Identifier Consult instructions for use Temperature limit...
-
Page 16: I.ii General Information - Valid For Mano5001Lv
The order code of your device can be found on the type label on the device or on the packaging. Purpose MANO 5 is a system for magnifying text and pictures. Declaration of Conformity (DoC), CE/FCC mark You can request a copy of the declaration of conformity in written form from Reinecker Vision GmbH, Sandwiesenstr. - Page 17 Repair and maintenance The device may only be serviced and repaired by Reinecker Vision GmbH or an authorized dealer. Environmentally friendly disposal The device contains electronic components. To avoid environmental damage, the respective country-specific laws and regulations for the disposal of the device must be...
-
Page 18: Safety Instructions
2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. 4. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement. - Page 19 10. Do not try to repair or to dismantle the system on your own. That would immediately void the warranty. If you need any technical assistance please contact your distributor or Reinecker Vision GmbH. 11. Always turn the system OFF and disconnect it from the power supply before cleaning it.
-
Page 20: Instructions
III. Instructions 1. Scope of supply ● MANO 5 ● charging cable with ● Li-Ion battery power adapters ● battery cover ● microfiber cloth ● battery cover with handle ● quick start guide ● carrying case ● user manual 2. Commissioning... -
Page 21: Charging The Battery
Connect the supplied charging cable to the power adapter and connect the supplied cable to the power port on the unit. Plug the power adapter into an AC outlet and start charging MANO 5. Caution: The AC adapter supplied with the unit is designed to operate... -
Page 22: Battery Handling
AC outlet. ● If MANO 5 is not in use for a longer period of time, the battery discharges automatically. Always check charging status to avoid complete discharge which would damage the unit. -
Page 23: Power Indicator
Power indicator The symbol of the power indicator lights up in different colors, which can be used to indicate different charging states: Device switched OFF, power supply connected: ● Green power indicator: device is charging ● Power indicator OFF: device is fully charged Device switched ON: ●... -
Page 24: Writing Stand
Writing stand Open the writing stand as the following figure shows. And you can write under the camera. -
Page 25: Attaching The Foldable Handle
Attaching the foldable handle A foldable handle can be attached to the rear by replacing the battery cover. To do this, remove the battery cover as described on page 20. Unfold the cover with handle and slide it back until it clicks into place. -
Page 26: Operation
3. Operation Compositions Front... - Page 27 Bottom 1) LCD display screen 6) ON/OFF button 2) zoom in (elevated dot) 7) loudspeaker 3) color mode 8) freeze image 4) zoom out (tactile indentation) 9) power port 5) status LED...
- Page 28 Back 10) stand 12) LED lighting 11) camera 13) battery compartment...
-
Page 29: Turning On/Off
Turning ON/OFF To turn ON MANO 5 press and hold the power button for approx. 3 seconds. Press and hold the power button for approx. 3 seconds to turn OFF the device. Briefly press the power button to view the status of the battery, color mode, freeze/live image, and the acoustic signals. -
Page 30: Acoustic Signals
Acoustic signals If this function is active, you will hear an acoustic signal for the following status messages: ● Device ON/OFF ● Threshold reached ● Pressing any button ● Battery low Press and hold the freeze button for approx. 3 seconds to turn ON/ OFF the acoustic signals. -
Page 31: Color Modes
Color modes A color mode is a pre-defined color combination. Full color mode is suit- able for viewing pictures or maps. Artificial color mode is a combination of contrasting foreground and background colors and can help to read more clearly. Tap the color mode button to cycle between the different color modes. - Page 32 The following color combinations are available in the different artificial color combination lists: Simplified: true color mode white on black black on white Standard (default setting): true color mode white on black black on white yellow on black black on yellow...
-
Page 33: Brightness
Extended: true color mode white and black black and yellow white and blue blue and yellow green and black black and violet black and blue green and white red and white red and black Brightness Set the display brightness for full color mode and artificial color mode. The factory default value is highlighted in green. -
Page 34: Contrast Adjustment (Artificial Color Mode)
Contrast adjustment (artificial color mode) Fine-tuning the combination of foreground and background color in an artificial color mode improves the image quality of different materials. The factory default value is highlighted in green. Press the power button and the color mode button simultaneously to change the contrast. - Page 35 Press the freeze button to lock the active image. Press the freeze button again to release it. You can move the magnified image as follows: power button and zoom + button: move image to the right or up power button and zoom - button: move image to the left or down If you want to switch from the horizontal direction of move- ment to the vertical direction, briefly press both the power...
-
Page 36: Memory
Memory MANO 5 will memorize automatically the most recent settings, such as color mode, magnification, acoustic signals when power is OFF and recall them when the system is ON next time. Energy saving mode If this function is activated, the unit will automatically turn OFF if there is no operation or movement for more than 3 minutes. -
Page 37: Reset To Default Factory Settings
Reset to default factory settings Press and hold the freeze button and zoom out button simultaneously for approx. 3 seconds to reset the current settings to the factory defaults. After resetting, the unit turns OFF automa- tically. -
Page 38: Troubleshooting
IV. Troubleshooting The device cannot be switched ON ● Connect the power adapter and charge the battery ● Check if the battery is inserted The device cannot be switched OFF ● Remove the battery and re-insert it Black or white screen ●... - Page 39 The image does not change ● Check if the unit is in freeze mode ● Press the power button to check the current status ● Switch the device OFF and ON again Dirt or stains on the screen ● Adjusting brightness ●...
-
Page 40: Warranty Information
V. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty peri- od only valid within the European Union) against defects in manufac- ture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automati- cally become property of Reinecker Vision GmbH. - Page 41 The manufacturer does not carry the cost for transport, packaging and insurance. Prior to returning the system, a RMA number issued by Reinecker Vision is required. Please have the exact serial number of your system before hand.
-
Page 42: Technical Details
VI. Technical details type MANO 5 (MANO5002/ MANO5002LV) 5" LCD display with screen approx. 12,7 cm screen diagonal magnification approx. x4 to x20 color modes true color, up to 19 artificial colors adjustable freeze image freeze image function, WxHxD approx. 15.2 x 8 x 2.2 cm / measurements 6 x 3.1 x 0,9 inch... - Page 44 Manufacturer / Hersteller In case service is necessary, please Reinecker Vision GmbH contact your autho- sales department, customer relations: rized distributor. Vertrieb, Kundenberatung: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein Bitte wenden Sie sich bei Fragen oder einem customer service: Servicefall direkt an...
