Reinecker MANO XL User Manual

Hide thumbs Also See for MANO XL:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MANO XL
Please read this user
manual carefully
prior to installation,
use and maintenance
for your own safety
and in order to avoid
damages on your
system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANO XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Reinecker MANO XL

Summary of Contents for Reinecker MANO XL

  • Page 1 User Manual MANO XL Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.

  • Page 3: Table Of Contents

    II. Safety instructions ........9 III. Instructions on the use of MANO XL ..... . . 10 Scope of delivery .

  • Page 4: General Information

    Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO XL is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes.
  • Page 5 Product description MANO XL is a system to magnify text and images with the following benefits: ● 7" LCD-Display (approx. 17,8 cm). ● continuous magnification ranges from approx. 2x – 37x. ● ergonomic and compact design with fold-out stand for easy use.

  • Page 6: General Information - Valid For Manoxl03

    Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation.
  • Page 7 OFF and the battery must be taken out. Please do not switch ON the device again. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Reinstatement, installation and maintenance This device may be technically repaired and reconditioned by Reinecker Vision GmbH only or by an authorized technician.

  • Page 8: I.ii General Information - Valid For Manoxl03Lv

    The order code of your device can be found on the type label on the device or on the packaging. Purpose MANO XL is a system for magnifying text and pictures. Declaration of Conformity (DoC), CE/FCC mark You can request a copy of the declaration of conformity in written form from Reinecker Vision GmbH, Sandwiesenstr.

  • Page 9: Safety Instructions

    2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. 4. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement.

  • Page 10: Instructions On The Use Of Mano Xl

    ● User manual ● HDMI cable (1,5 m) Commissioning Before using MANO XL for the first time, you have to charge the battery. Further information can be found under „Battery Charging“ on page 12. Compositions 1. LCD Screen 4. joystick 2.
  • Page 11 7. rear camera 8. LED lights 9. reading/writing stand 10. ON/OFF button 13. freeze button 11. line marker and 14. HDMI port mask + search function 15. power port 12. USB port 16. focus control...

  • Page 12: Battery Charging

    Battery Charging ● Connect the supplied power cable to the power adapter. ● Connect the supplied power cable to the unit’s power port. ● Plug the power adapter into an AC outlet and start charging. Power LED Charging when the unit is OFF, the power LED will be green, and then auto turn OFF when fully charged.

  • Page 13: Integrated Stand

    Integrated Stand With integrated foldaway writing stand at an ergonomic viewing angle, MANO XL can satisfy users’ desire to read more and for a long time in a comfortable position. Also, there’s enough space under the camera to work the pen. Unfold the stand as the following figure shows.

  • Page 14: Magnification

    Magnification Press the zoom in button to increase the magnification step by step or hold the zoom in button for continuous magnification. Press the zoom out button to decrease magnification and hold the zoom out button for continuous decrease. Magnification range when standing on table: 2x – 37x Color Mode A color mode is a predefined color combination.

  • Page 15: Contrast (In Enhanced Color Mode)

    Contrast (in Enhanced Color Mode) The contrast of the screen can be adjusted in the enhanced color mode. Press and hold the enhanced color button and press the zoom in button to increase the brightness. Press and hold the enhanced color button and press the zoom out button to decrease the brightness.

  • Page 16: Focus Control

    Focus Control Click the focus control button to lock the focus, a red frame appears around the screen, which is especially useful when hand- writing. Click the focus control button again to unlock the focus, the red frame disappears Image freeze Freezing an image on the LCD screen can be useful for further reading.

  • Page 17: Line & Mask

    When in the gallery, press the locate button to select the target image which needs to be deleted. Press the locate button again to confirm, or any other buttons to cancel. When in the gallery, hold the locate button for 5 seconds to delete all images.

  • Page 18: Find

    Horizontal mask Press and hold the locate button and slide the joystick up/down to change the position of the masks. Slide the joystick left/right to narrow/enlarge the distance between the masks. Vertical mask Press and hold the locate button and slide the joystick left/ right to change the position of the masks.

  • Page 19: Memory

    For example, if you have finished reading a horizontal line and want to read from the beginning of the next line, please hold the ON/OFF button and slide the joystick left or just quickly push the joystick left twice. The start point or end point will be auto recorded and refreshed according to the maximum navigation range when reading.

  • Page 20: Auto Power Saving

    Auto Power Saving If no operation and no move for over 3 minutes, the unit will turn OFF automatically. Press and hold the ON/OFF button and click the enhanced color button to turn ON/OFF the Auto power Saving function manually (factory default is ON). (Pay attention to the moon symbol) Restore to Factory Settings Long press the freeze button and the locate button at the...

  • Page 21: Warranty Information

    Please contact your local distributor if problem is not solved. V. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH.

  • Page 22: Technial Details

    VI. Technial Details Type MANO XL (MANOXL03/MANOXL03LV) 7-inch wide LCD, Display 1280 x 720 pixel system resolution 13 MP / video resolution: 1920 x 1080 pixel, Camera autofocus Magnification approx. 2x - 37x true color; Color mode up to 16 enhanced color modes adjustable Size (W x H x D) approx.
  • Page 24 Manufacturer In case service is necessary, please Reinecker Vision GmbH contact your autho- International Contact rized distributor. sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach- Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311-0 Fax: +49 6257 9311- 8230 E-Mail: international@reineckervision.de...

This manual is also suitable for:

Manoxl03Manoxl03lv
