Summary of Contents for Reinecker MANO 16
- Page 1 User manual MANO 16 Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.
-
Page 3: Table Of Contents
Scope of supply ......................10 Accessories ( optional ) .....................10 Commissioning ......................10 Charging the battery ....................10 Power indicator ......................10 Setting up MANO 16 ....................10 Unfolding MANO 16.................... 11 Attaching the anti-glare shield ................12 Description of the controls ..................13 Operation ........................14 Turning ON/OFF ......................14 Home/menu button ....................14... - Page 4 Settings........................21 Options page ......................21 Individual color combinations ................21 Voice label ......................21 Power saving (standby mode) ................21 Touch Screen ......................21 Keystone Correction ...................21 Speech guide ......................21 Language settings .....................21 Male / female voice selection ................21 Language selection ....................21 Device information .....................21 Reset to factory settings ..................21 Frequency ......................22 User Interface .....................22...
-
Page 5: General Information
Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO 16 is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes. -
Page 6: General Information - Valid For Mano1601
Always ask your doctor, pharmacist or a person you trust about dosing of medications! Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. Caution: The use of any other power supply besides the original, might lead to an increased electro-magnetic emission and to product damage. - Page 7 Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation. Safety advice The device has to be set up and operated in closed and dry rooms only.
-
Page 8: I.ii General Information - Valid For Mano1601Lv
Repair and maintenance The device may only be serviced and repaired by Reinecker Vision GmbH or an authorized dealer. Environmentally friendly disposal The device contains electronic components. -
Page 9: Safety Instructions
Do not touch the AC adapter with wet hands. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement. -
Page 10: Instructions
Setting up MANO 16 MANO 16 has a stand that holds the display in a comfortable reading position. There is a carrying handle on the housing for safe transportation. Note: Carefully remove the device from the packaging and place it on a stable... -
Page 11: Unfolding Mano 16
Unfolding MANO 16 Place the transportable video magnifier on a stable surface and hold the base plate firmly with one hand. Use your other hand to pull up the handle to move the display upwards. Keep pressing the tray and unfold the arms to a suitable angle. -
Page 12: Attaching The Anti-Glare Shield
Attaching the anti-glare shield Depending on the ambient light, distracting reflections on your reading material can make reading difficult. In this case, you can attach the anti-glare shield to the back of the stand. Peel the sticker cover off the back of the shield and stick it to the back of the device as shown in the images (images show a MANO EDU model with distance camera). -
Page 13: Description Of The Controls
Description of the controls 1) DC port 6) home 11) microphone 2) ON/OFF 7) color mode 12) headphone / 3) SD card slot 8) joystick loudspeaker socket 4) gallery 9) zoom 13) volume +/- 5) line/mask button 10) enter 14) autofocus 15) freeze frame 16) LED lighting 19) battery lock... -
Page 14: Operation
When the unit is ON, press the ON/OFF button to check the current status of the battery capacity. When the unit is ON, press and hold the ON/OFF button to turn OFF MANO 16. A menu appears in which you can choose to either switch MANO 16 to standby mode or to turn it OFF. -
Page 15: Color Mode
Color mode Full color mode is suitable for displaying pictures or maps. In semi color mode (a combination of foreground and background color), texts can be read with high contrast. Rotate the color mode button to cycle through all activated semi color combinations. Press the color mode button to quickly switch between true color mode and the last selected semi color. -
Page 16: Live Panning
Live Panning In a higher zoom level, use the slide gesture (or use the Joystick ) to navigate the image for seeing more without moving the paper. Push the joystick in any direction and turn the zoom button to display the bar for the panning speed. To adjust the panning speed, turn the magnification button or adjust the slider on the screen with your finger to the desired position. -
Page 17: Freeze Frame Function
Briefly press the autofocus button to activate or deactivate it. If you want to write under MANO 16, turn the autofocus OFF before you place your hand under the display to write something. This will prevent the hand or the pen... -
Page 18: The Main Menu
SD card or a USB stick. If you want to view external pictures, text files or PDFs on MANO 16, you can copy them from an SD card or USB stick to the device. -
Page 19: Copy Files From An Sd Card/Usb Stick To The Device
Copy files from an SD card/USB stick to the device In the open document/picture menu, open the SD card (2) or USB stick (3), select the desired files, and press the copy icon in the left column. Supported picture formats are JPG, BMP, PNG, and TXT, PDF for documents. -
Page 20: Open And View Pictures
Open and view pictures Open the pictures folder on the device or SD card/USB stick. There you can scroll up or down with the slider on the right side of the screen or with the joystick. Tap the thumbnail to highlight it and tap it again (or press the enter button) to view the picture. -
Page 21: Settings
Settings The last item in the main menu are the settings. You can choose from the following submenus: Options language settings Device information Tap the submenu you want (or rotate the Color Mode button) to see the available options. Tap on the item to change the settings (or press the joystick to highlight the item and press the enter button to change it). -
Page 22: Frequency
Frequency Frequency offers the options 50 Hz and 60 Hz which can be changed depending on the region in which you are located. If the picture flickers, changing the frequency can lead to an improvement. User Interface Here you can choose between Standard and Simple. In simple mode, only the basic functions of a magnifying system are available: ●... -
Page 23: Troubleshooting
● Tap the screen for 2 seconds to manually set the focus. If the problem is not solved, reset the device to factory settings and perform a hardware reset. If you have any further problems, please contact Reinecker Vision GmbH... -
Page 24: Warranty Information
V. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH. -
Page 25: Technical Details
VI. Technical details Type MANO 16 (MANO1601/MANO1601) FullHD 15.6" (approx. 39.5 cm) touch display on a tiltable Display stand, screen resolution: 1920 x 1080 Cameras Ultra HD 4K camera, video resolution: 3840 x 2160 Document view: 1.4x - 54x Zoom... - Page 28 Manufacturer In case service is necessary, please contact your authorized distributor. Reinecker Vision GmbH International Contact sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311- 0 Fax: +49 6257 9311- 8230 Email: international@reineckervision.de...
