  • Page 1 User manual MANO 12 Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.

  • Page 3: Table Of Contents

    Operation of MANO 12 ........

  • Page 4: General Information

    Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO 12 is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes.
  • Page 5 Product description MANO 12 is an electronic magnifier for enlarging text and images and for converting and reproducing printed text into synthetic speech: ● the 12-inch LCD display (approx. 29.4 cm diagonal) offers an extremely sharp and high-contrast image ●...

  • Page 6: General Information - Valid For Mano1202

    Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation.
  • Page 7 OFF and the battery must be taken out. Please do not switch ON the device again. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Reinstatement, installation and maintenance This device may be technically repaired and reconditioned by Reinecker Vision GmbH only or by an authorized technician.

  • Page 8: I.ii General Information - Valid For Mano1202Lv

    The order code of your device can be found on the type label on the device or on the packaging. Purpose MANO 12 is a system for magnifying text and pictures. Declaration of Conformity (DoC), CE/FCC mark You can request a copy of the declaration of conformity in written form from Reinecker Vision GmbH, Sandwiesenstr.

  • Page 9: Safety Instructions

    2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. 4. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement.

  • Page 10: Instructions

    Description of the two stand variants MANO 12 can be used quickly and compactly with the integrated stand or with the foldable reading/writing stand included in the scope of delivery. With the help of the reading/writing stand, you can write comfortably or conveniently view thicker objects such as food packaging under the mag- nifier.
  • Page 11 Use of the foldable reading/writing stand The reading/writing stand is a useful extension to the MANO 12 and can be packed together with the reading magnifier in the carrying case. Unfolding the reading/writing stand fold down Side arms press lift...

  • Page 12: Operation Of Mano 12

    Charging socket Switch ON/OFF Press the ON/OFF button for three seconds to switch the MANO 12 ON. You switch the device OFF in the same way. Standby mode In standby mode, the screen is switched OFF but the device remains switched ON.

  • Page 13: Near/Distant View

    Near/distant view Open or close the stand to switch between near and far view mode. Zoom (-/+) Press the plus button to enlarge the view and the minus button to reduce the view. To navigate in the enlarged image section, move the joystick up / down / left / right.

  • Page 14: Display And Save Freeze Images

    3 seconds or press the door symbol in the bottom right of the display. Text recognition and read aloud function Lay your document flat under MANO 12 and tap the screen if necessary to focus the document. Briefly press the camera button to capture the document. Text recognition starts and the document is automatically rotated.

  • Page 15: Various Display Modes

    Tip: Have DIN A4 documents read aloud To record a DIN A4 document in one step, you must use the MANO 12 with the separate reading/writing stand and place the document horizon- tally under the magnifier. Tip: The best way to capture documents Text recognition is best suited to reading normal-sized printed text in a single column.

  • Page 16: Operation In Read-Aloud Mode

    White on black Black on white Yellow on black Black on yellow Reading aloud from a certain point Tap any word with your finger and MANO 12 will start reading it aloud at this point.

  • Page 17: Read Out Saved Documents From The Gallery

    12 reads out the text. PDF files You can transfer PDF files from your PC to MANO 12 as described in „Transferring files from a computer“ on page 23. These files can be read out page by page. When you select a PDF file, you will see a circle in the top right-hand corner indicating the current page and the total num- ber of pages in the PDF.

  • Page 18: Main Menu

    Main menu Open/ exit main menu In the live view, briefly press the Home button to open the main menu. Press the home button, the camera button or tap the back icon to close the main menu. There are six options in the main menu: 1 Read aloud function 2 Gallery 3 Distance camera...

  • Page 19: Gallery

    If you open the gallery in read- aloud mode, TXT/RTF is displayed as the third icon. Distance camera MANO 12 can be connected to a distance camera via the USB-C port. Please contact Reinecker Vision for more information. Settings...
  • Page 20 Screen brightness Slide the joystick to the left or press the magnification buttons to change the screen brightness. You can also tap on the displayed bar to adjust the screen brightness. To confirm, press the color mode button or tap "OK". To exit the setting, press the camera button or tap "Back".
  • Page 21 Color mode You can hide unneeded semi colors here. Press the joystick right / left / up / down to switch between the colors. Press the color mode button to deactivate or activate a specific color mode. Alternatively, you can also tap the corresponding color combination with your finger. A crossed-out symbol means that this color combination is hidden.

  • Page 22: System Information

    Firmware version You can view the current firmware version of MANO 12 here. OCR and read-aloud function No further settings need to be made here, as MANO 12 has an OCR and read-aloud function as standard. Standby mode ON/OFF To switch standby mode ON or OFF, either tap the icon or press the color mode button.

  • Page 23: Transferring Files From A Computer

    Connect the computer and MANO 12 using the USB cable supplied. How to transfer files: You can find the files saved on MANO 12 under the following file path: This PC\UltraOcta A80 OptimusBoard\MANO 12\DCIM. Files are stored in the following folders: ●...

  • Page 24: Connection To A Television Or Monitor

    Output input You can also transmit the camera image from MANO 12 to a TV or mon- itor. Connect MANO 12 to your external display device using the HDMI cable included in the scope of delivery. With most televisions, the input source must be changed in order to display the image from MANO 12.
  • Page 25 Note: If the battery is almost empty, a red battery symbol appears at the bottom left of the screen and the status LED lights up red. The device switches itself OFF shortly afterwards unless you charge it. Battery life and charging time When the battery is fully charged, the operating time is up to approx.

  • Page 26: Troubleshooting

    IV. Troubleshooting Problem 1: Black screen Solution: ● Make sure that the device is switched ON and not in standby mode. ● Charge the battery. ● Reduce the magnification level. Problem 2: The image on the screen is dark or distorted Solution: ●...
  • Page 27 Problem 7: All other problems not mentioned in this manual. Solution: ● Press the ON/OFF button and the Plus button simultaneously to force the system to restart. If none of the above solutions help you, please contact your dealer or Reinecker Vision GmbH.

  • Page 28: Warranty Information

    V. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH.

  • Page 29: Technical Details

    VI. Technical details Type MANO 12 (MANO1202/MANO1202LV) 12" touchscreen with approx. 29.4 cm diago- Screen Screen resolution 1920 x 1080 pixel Camera 13 megapixel approx. 2.7 to 19x Magnification approx. 2.5 to 19x on separate read/write stand Storage capacity approx. 13 Gigabyte Dimensions approx.
