  • Page 1 User manual MANO EDU lite Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.
  • Page 3: Table Of Contents

    Commissioning ......................10 Charging the battery ....................10 Power indicator ......................10 Setting up MANO EDU lite ..................11 Unfolding the MANO EDU lite stand ..............11 Folding the stand ....................11 Attaching the distance camera ................11 Description of the controls ..................12 Operation ........................13...
  • Page 4 Open pictures ......................20 Open documents .......................20 Read aloud function (for PDF and TXT files) ............20 View and read aloud text files ................20 View and read aloud PDF files ................21 Settings........................21 Options page ......................21 Language settings .....................21 Device information .....................22 HDMI output ......................22 Hardware reset ......................22 Handling of the battery ....................23 Replacing the battery..................23...
  • Page 5: General Information

    Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO EDU lite is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes.
  • Page 6: General Information - Valid For Manedli1

    Always ask your doctor, pharmacist or a person you trust about dosing of medications! Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. Caution: The use of any other power supply besides the original, might lead to an increased electro-magnetic emission and to product damage.
  • Page 7 Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation. Safety advice The device has to be set up and operated in closed and dry rooms only.
  • Page 8: I.ii General Information - Valid For Manedli1Lv

    The device may only be connected to a state-of-the-art circuit. Repair and maintenance The device may only be serviced and repaired by Reinecker Vision GmbH or an authorized dealer. Environmentally friendly disposal The device contains electronic components.
  • Page 9: Safety Instructions

    Do not touch the AC adapter with wet hands. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement.
  • Page 10: Instructions

    III. Instructions Scope of supply ● MANO EDU lite ● Power supply with adapters ● external distance camera ● quick reference guide ● carrying bag ● user manual ● cleaning cloth Accessories ( optional ) ● MultiView screen ● spare battery ●...
  • Page 11: Setting Up Mano Edu Lite

    Setting up MANO EDU lite Unfolding the MANO EDU lite stand MANO EDU lite can be used in a comfortable reading position by using the integrated, folding stand. Fold out the stand and place the device on top of your reading material...
  • Page 12: Description Of The Controls

    Description of the controls 1) ON/OFF 7) SD card slot 14) volume +/- 2) DC port 8) front camera 15) distance camera 3) HDMI output 9) home connection 4) headphone / 10) color mode 16) autofocus loudspeaker socket 11) joystick 17) freeze frame 5) camera switch 12) zoom...
  • Page 13: Operation

    Turning ON/OFF Press and hold the ON/OFF button for 3 seconds to turn on MANO EDU lite. When the unit is ON, press the ON/OFF button to check the current status of the battery capacity.
  • Page 14: Full-Page Reading (With Plug-In Distance Camera)

    Full-page reading (with plug-in distance camera) The device can capture an entire DIN A4 with the distance camera in document mode. You can then view the page enlarged and move it without having to move the reading material. For more information on correct camera positioning, see „Functions of the external camera“...
  • Page 15: Volume

    Operating the cameras Switching between close-up and long-distance view When the stand is folded in, MANO EDU lite is in distance viewing mode to make it easier to see things further away. When you unfold the stand, the device automatically switches to close-up mode and you can place the device on the reading material.
  • Page 16: Functions Of The External Camera

    MANO EDU lite. You can also write comfortably under the external camera on the right side of the device. There is a built-in light on the camera that can improve the image in low light conditions.
  • Page 17: Overview Mode

    Briefly press the autofocus button to activate or deactivate it. If you want to write under MANO EDU lite, turn the autofocus OFF before you place your hand under the display to write something. This will prevent the hand or the...
  • Page 18: The Main Menu

    SD card. If you want to view external pictures, text files or PDFs on MANO EDU lite, you can copy them from a PC, laptop or an SD card to the device.
  • Page 19: Copy Files From An Sd Card To The Device

    Copy files from an SD card to the device In the open document/picture menu, open the SD card (2), select the desired files, and press the copy icon in the left column. Supported picture formats are JPG, BMP, PNG, and TXT, PDF for documents. You will then find these files in the Shared Picture (4) and Shared Document (5) folders.
  • Page 20: Open Pictures

    Open pictures Open the pictures folder on the device or SD card. There you can scroll up or down with the slider on the right side of the screen or with the joystick. Tap the thumbnail to highlight it and tap it again (or press the enter button) to view the picture.
  • Page 21: View And Read Aloud Pdf Files

    View and read aloud PDF files Tap one of the arrows in the menu bar to scroll back/forward one page. Press and hold to scroll back/forward first 10 and then 50 pages at a time. Tap one of the double arrows in the menu bar to go to the beginning or end of the PDF..
  • Page 22: Device Information

    Device information Reset to factory settings Here you can reset the device to the factory settings. After the reset, the device will automatically turn OFF. Frequency Frequency offers the options 50 Hz and 60 Hz which can be changed depending on the region in which you are located.
  • Page 23: Handling Of The Battery

    Handling of the battery Attention: A prerequisite for a long battery life is the correct operation and charging of the battery. Make sure the battery is fully charged before first use of the system. For charging, connect the power adapter with the power port on the left side of the system and plug it into an AC outlet.
  • Page 24: Troubleshooting

    Check whether the user interface is set to Simple in the menu under “Device information” If the problem is not solved, reset the device to factory settings and perform a hardware reset. If you have any further problems, please contact Reinecker Vision GmbH...
  • Page 25: Warranty Information

    V. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH.
  • Page 26: Technical Details

    VI. Technical details Type MANO EDU lite (MANEDLI1/MANEDLI1LV) FullHD 12.5" (approx. 31.8 cm) touch display, Display screen resolution: 1920 x 1080 Cameras Ultra HD 4K camera, video resolution: 3840 x 2160 Document view: 2.2x - 50x Zoom (depending on the viewing angle)
  • Page 28 Manufacturer In case service is necessary, please contact your authorized distributor. Reinecker Vision GmbH International Contact sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311- 0 Fax: +49 6257 9311- 8230 Email: international@reineckervision.de...
