User Manual
MANO XXL
Please read this user
manual carefully
prior to installation,
use and maintenance
for your own safety
and in order to avoid
damages on your
system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANO XXL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Reinecker MANO XXL

Summary of Contents for Reinecker MANO XXL

  • Page 1 User Manual MANO XXL Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.

  • Page 4: Table Of Contents

    II. Safety instructions ........11 III. Instructions on the use of MANO XXL ..... . 12 Scope of delivery .
  • Page 5 Find ........... . 21 Live Panning .

  • Page 6: General Information

    Please read them carefully prior to the operation of the device! Notes on the electromagnetic compatibility (EMC) MANO XXL is suited for the use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes.
  • Page 7 Product description MANO XXL is a system to magnify text and images with the following benefits: ● 10“ LCD-Display (approx. 25,4 cm). ● Continuous magnification ranges from approx. 2x – 32x. ● ergonomic and compact design with fold-out stand for easy use.

  • Page 8: General Information - Valid For Manxxlp3

    Combination with other medical devices If the operator/user wants to operate this device in conjunction with other life sustaining medical devices, please get in touch with Reinecker Vision GmbH or with your local dealer, prior to operation.
  • Page 9 OFF and the battery must be taken out. Please do not switch ON the device again. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Reinstatement, installation and maintenance This device may be technically repaired and reconditioned by Reinecker Vision GmbH only or by an authorized technician.

  • Page 10: I.ii General Information - Valid For Manxxlp3Lv

    The order code of your device can be found on the type label on the device or on the packaging. Purpose MANO XXL is a system for magnifying text and pictures. Declaration of Conformity (DoC), CE/FCC mark You can request a copy of the declaration of conformity in written form from Reinecker Vision GmbH, Sandwiesenstr.

  • Page 11: Safety Instructions

    2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. 4. If the system is equipped with batteries, only original parts from Reinecker Vision GmbH should be used for replacement.

  • Page 12: Instructions On The Use Of Mano Xxl

    ● User manual ● HDMI cable (1,5 m) Commissioning Before using MANO XXL for the first time, you have to charge the battery. Further information can be found under „Battery Charging“ on page 14. Compositions 1. LCD Screen 5. joystick 2.
  • Page 13 8. rear camera 9. LED lights 10. reading/writing stand 11. ON/OFF button 15. freeze button 12. power port 16. camera switch 13. HDMI port 17. power port 14. line marker and 18. focus control mask + search function...

  • Page 14: Battery Charging

    Battery Charging ● Connect the supplied power cable to the power adapter. ● Connect the supplied power cable to the unit’s power port. ● Plug the power adapter into an AC outlet and start charging. Power LED Charging when the unit is OFF, the power LED will be green, and then auto turn OFF when fully charged.

  • Page 15: Integrated Stand

    Integrated Stand With integrated foldaway writing stand at an ergonomic viewing angle, MANO XXL can satisfy users’ desire to read more and for a long time in a comfortable position. Also, there’s enough space under the camera to work the pen. Unfold the stand as the following figure shows.

  • Page 16: Operation

    Operation ON/OFF button Press and hold the ON/OFF button for 3 seconds to turn ON/OFF the unit. When the unit is ON, press the ON/OFF button to check the current status of battery capacity, freeze mode, focus status, and beep. Press other buttons when holding the ON/OFF button will make combo functions.

  • Page 17: Color Mode

    Color Mode A color mode is a predefined color combination. Full color mode is suitable for viewing pictures or maps. Enhanced color mode is combined with different foreground and background colors which can help to read more clearly. Press the enhanced color button, to go through the enhanced color combination list.

  • Page 18: Brightness

    Brightness Brightness of the screen can be adjusted in both full color mode and enhanced color mode. Press and hold the ON/OFF button and press the zoom in button to increase the brightness. Press and hold the ON/OFF button and press the zoom out button to decrease the brightness.

  • Page 19: Image Freeze

    Image freeze Freezing an image on the LCD screen can be useful for further reading. At this status, magnification as well as color change is still allowed for a better experience. Press the freeze button to lock the active image. Press the freeze button again to unlock.

  • Page 20: Line & Mask

    Use the joystick and true color button to choose the target pictures and you can delete the selected pictures at once. Pressing the locate button will pop up a confirm box. Press the true color button to confirm deletion and the enhanced color button to cancel.

  • Page 21: Find

    Normal, no line & mask Pressing the ON/OFF button will quickly exit the line & mask modes. Find Long press the locate button, until a red location box appears. Move and change the content in the location box, aiming it at the part you want to view, and then press the locate button, again and the image will return back to the previous magnification with the refreshed content.

  • Page 22: Change Refresh Rate (60Hz To 50Hz)

    Change refresh rate (60Hz to 50Hz) Press and hold the ON/OFF button and the color button for about 3 seconds, to change the refresh rate from 60Hz to 50Hz or the other way around. Change when necessary, only if there is a unpleasant flicker on the screen.

  • Page 23: Foldable Reading/Writing Stand

    IV. Foldable Reading/Writing Stand Construction Locking function Slot of tray for MANO XXL Unfold procedure Step 1: Separate the legs apart.

  • Page 24: Use Case

    Step 2: Split the legs to form the V shape. Step 3: Slide the MANO XXL into the slot of tray until it locks into place. Use Case The stand is multi-functional to assist: ● Reading ● Handwriting ● Far view ●...

  • Page 25: Case 1: Reading Mode

    Case 1: Reading Mode Adjust your comfortable reading angle. Note: With the built-in auto recognition mechanism, the device can auto recognize the stand and turn ON the lights for a better experience. Warning: Never look directly into the light source. This could damage your eyes.

  • Page 26: Case 2: Handwriting Mode

    Case 2: Handwriting Mode The first steps are the same as for handwriting mode (see variant 1): Tilt the MANO to the reading angle that is most comfortable for you. There are four light statuses which can be applied to help the hand- writing: lights all OFF lights all ON...

  • Page 27: Case 3: Far View

    Shadow reducing when handwriting For example, if you are left-handed, turn OFF the left LED light. If you are right-handed, you can turn OFF the right LED light to reduce the shadow. Case 3: far view Adjust the viewing angle as the picture shows. Rotate the device around and face the back camera to the object which you want to view.

  • Page 28: Case 4: Mirror View

    Case 4: mirror view Rotate the device around and face the front camera to the object which you want to view. Turn the camera switch right to open the front camera for mirror view. Fold procedure The folding procedure is as simple as unfolding. Step 1:...
  • Page 29 Step 2: Attention: Be careful not to jam your fingers when folding the legs of the stand. Step 3: Step 4:...

  • Page 30: Troubleshooting

    V. Troubleshooting The unit does not turn ON ● Connect to the power adapter ● Charge the battery ● Hardware Reset Black screen or White screen ● If the unit is sitting on a flat pure surface, the screen may be black or white.

  • Page 31: Warranty Information

    VI. Warranty information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH.

  • Page 32: Technical Details

    VII. Technial Details Type MANO XXL (MANXXLP3/MANXXLP3LV) Display 10-inch wide LCD, HD screen Camera autofocus, HD Magnification approx. 2x - 32s true color; Color mode up to 16 enhanced color modes adjustable Size (W x H x D) approx. 24,5 x 2,2 x 20 cm Weight approx.
  • Page 36 Manufacturer In case service is necessary, please Reinecker Vision GmbH contact your autho- International Contact rized distributor. sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach- Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311-0 Fax: +49 6257 9311- 8230 E-Mail: international@reineckervision.de...

This manual is also suitable for:

Manxxlp3Manxxlp3lv
