• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Assembly
WARNING
Danger of injury!
Only insert the mains plug into the socket when the
product is ready for use.
• Place the product on a level, even surface (such that it
cannot topple).
Tool required:
• Phillips screwdriver*
* = may not be included in the scope of delivery!
8.1 Fitting the holders (Fig. 3)
1. Slide the holder (10) for the mains connection cable
and the lance holder (3) onto the two connection
points on the side of the product.
8.2 Mounting the handle (1) (Fig. 4)
1. Slide the handle (1) onto the connection on the top of
the product and fix it with two screws (1a).
Use a Phillips screwdriver for it.
8.3 Connecting the coupling (12a) for
the water connection (12) (Fig. 5)
1. Remove the cover cap on the water connection (12).
Keep the cover cap.
2. Screw the coupling (12a) onto the water connection
(12).
9 Before commissioning
In accordance with applicable regulations, the product
must never be operated on the drinking water network
without a system separator.
A suitable system separator in accordance with EN 12729
type BA must be used.
Water that has flowed through a system separator back-
flow prevention device is considered non-potable.
A system separator is available from specialist dealers.
A system separator (backflow preventer) prevents water
and cleaning agent from flowing back into the drinking
water pipe.
• Use a standard ½" garden hose with a length of at
least 5 m for the water inlet.
A length of 30 m should not be exceeded.
9.1 Connecting/removing the high
pressure hose (8) (Fig. 1, 2)
Connect:
1. Detach the high-pressure hose (8) from the fastening
clips (9a).
20 | GB
2. Unroll the high-pressure hose (8) completely from the
hose reel using the crank handle (9).
3. Remove the coupling plug of the high-pressure hose
(8) from the hose reel.
4. Attach the high pressure hose (8) to the connection
(6) on the high-pressure cleaner using the screw con-
nection.
5. Connect the coupling plug of the high-pressure hose
(8) to the connection (2c) of the spray gun (2).
The coupling plug engages audibly.
Remove:
1. Actuate the release (2d) on the spray gun (2) and pull
out the high-pressure hose (8).
2. Unscrew the high-pressure hose (8) from the connec-
tion (6) on the high-pressure cleaner.
3. Insert the coupling plug of the high-pressure hose (8)
into the hose reel.
4. Roll the high-pressure hose (8) onto the hose reel us-
ing the crank handle (9).
5. Attach the screw connection of the high-pressure
hose (8) to the fastening clips (9a).
9.2 Connecting/removing the lance (4)
(Fig. 1, 2)
Connect:
1. Insert the end of the lance (4) into the connection pro-
vided on the spray gun (2).
2. Press the lance (4) firmly into the connection of the
spray gun (2) and turn the lance (4) clockwise until it
is securely connected to the spray gun (2).
Remove:
1. Press the lance (4) firmly into the connection of the
spray gun (2) and turn it anti-clockwise.
2. Pull the lance (4) forwards.
9.3 Selecting the attachment (Fig. 2)
Select the appropriate attachment (14/15/16/17/18) for
the work to be carried out:
• Turbo nozzle (14):
The turbo nozzle (14) with its rotating water jet is par-
ticularly suitable for removing stubborn dirt.
• Variable nozzle (15):
The variable nozzle (15) with its flat jet is particularly
suitable for surface cleaning. The width of the water
jet can be adjusted by turning the nozzle tip.
• Kärcher adapter (16):
The Kärcher adapter (16) allows you to use Kärcher
brand accessories.
• Washing brush (17):
The washing brush (17) is always used without apply-
ing pressure. It is suitable for cleaning sensitive sur-
faces. The water flows through the bristles, which en-
ables even and gentle cleaning.
• Patio cleaner (18):
With its rotating nozzles, the patio cleaner (18) is suit-
able for even and thorough cleaning of large, flat sur-
faces. Move the patio cleaner (18) slowly and evenly
over the surface to be cleaned.
