- Page 1 PB-FD-005 PB-FD-007 CLEARVIEW® POWER BOARDS ELECTRIC SIDE STEPS FORD NEXT GEN RANGER | 2022 - CURRENT VOLKSWAGEN NF AMAROK | 2022 - CURRENT FORD EVEREST UB | 2022 - CURRENT POWER BOARDS INSTALLATION GUIDE VERSION 2.3...
-
Page 2: Introduction
Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au... -
Page 3: Table Of Contents
Contents Introduction Kit Contents Before You Start 6-10 Fitting Instructions Operation of Clearview Power Boards Maintenance FAQS Warranty Our Range clearviewaccessories.com.au... -
Page 4: Kit Contents
Kit Contents DESCRIPTION QUANTITY PARTS SUPPLIED 1 x Right (RF) Front Bracket Assembly 1 x Left (LF) 1 x Right (RM) *For illustrative Middle Bracket Assembly 1 x Left (LM) purposes only 1 x Right (RR) Rear Bracket Assembly 1x Left (LR) Spring Washer 12 x M6 Flat Washer... -
Page 5: Before You Start
IMPORTANT Clearview recommends installation of the Power Boards to be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. The installation should take approximately 3-4 hours. Incorrect installation may cause damage to your vehicle and possible personal injuries. -
Page 6: Fitting Instructions
Fitting Instructions Step 1 Installation of wiring 1.1 Remove LHS Passenger front + rear door sill panels and LHS Passenger front kick panel. Remove kick panel Remove front + rear sill panels Pry back side trim panel *For illustrative purposes only 1.2 REPEAT on RHS / Drivers side. - Page 7 Fitting Instructions IMPORTANT Clearview recommends this installation to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. Step 2 Installation of control unit and wiring Sensor Wire Harness Layout ECU and Wire Harness set in Passenger footwell area.
- Page 8 Sill Panel using supplied hardware (nuts, bolts and washers). IMPORTANT Clearview recommend a straight-edge tool to be used when mounting the top mounting brackets. This provides a guide to keeping them level and straight alongside the vehicle. Ensure the straight-edge tool is aligned with the flat edge on the mounting brackets only, not...
- Page 9 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding connectors on motor Passenger (left) Connector for wire harness. side motor wiring LM motor Passenger side wires are GREEN / YELLOW, and Driver side wires are / BLUE.
- Page 10 In some cases, the 'U shape' packing washers may need to be placed in between the front side of the bracket assembly and vehicle bracket mounting points to correctly position Clearview Power Boards. ‘U-Shape’ In these few instances, the M8 bolts used to hold top bracket to vehicle will packing washer need to be loosened to insert the 'U shape' washer.
-
Page 11: Operation Of Clearview Power Boards
To do this, open vehicle door first so Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed. -
Page 12: Maintenance
Caring for your Clearview Power Boards Whilst the motors don’t require maintenance, regular routine cleaning will help ensure the continued smooth operation of your Clearview Power Boards. Using a garden hose, rinse away any loose dirt and grime that has built up on the Power Boards, their arms, and the areas around them. -
Page 13: Faqs
FAQs Can I perform the installation myself? I already have something plugged into my recommend that installation OBD-II port, where am I going to plug the completed by professionals, as there is Power Board harness if it also uses the OBD-II electrical wiring involved as well as removal port? of vehicle trims. -
Page 14: Warranty
A receipt will be required to make a warranty claim on any Clearview® product. If we determine that a Clearview® Power Board is defective in materials or workmanship during the Warranty, we will either repair or replace the product. -
Page 15: Our Range
Our Range Towing Mirrors Power Boards Rock Tamers Tyre Spider Power Slides Easy Slides Expanda Slides Fridge Cage Cutlery Set Pantry Clip on Trays Cable Saver clearviewaccessories.com.au... - Page 16 Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 info@clearviewaccessories.com.au clearviewaccessories.com.au...
