CLEARVIEW® POWER BOARDS
ELECTRIC SIDE STEPS
*NB: Not suitable for Single-Cab or Extra-Cab.
For Dual-Cab range only.
FORD RANGER PXI/PXII/PXIII | 2011 - MY2010
FORD EVEREST UA/UAII | 2015 - 2022
MAZDA BT-50 UP/UR | OCT 2011 - JUN 2020
*NB: Not suitable for GT
INSTALLATION GUIDE
VERSION 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerBoards PB-FD-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ClearView PowerBoards PB-FD-001

  • Page 1 PB-FD-001 PB-FD-002 PB-FD-003 PB-FD-004 PB-MA-001 CLEARVIEW® POWER BOARDS ELECTRIC SIDE STEPS *NB: Not suitable for Single-Cab or Extra-Cab. For Dual-Cab range only. FORD RANGER PXI/PXII/PXIII | 2011 - MY2010 FORD EVEREST UA/UAII | 2015 - 2022 MAZDA BT-50 UP/UR | OCT 2011 - JUN 2020...
  • Page 2: Introduction

    Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au...
  • Page 3: Table Of Contents

    Contents Introduction Kit Contents Before You Start Fitting Instructions 6-10 Operation of Clearview Power Boards Maintenance FAQS Warranty Our Range clearviewaccessories.com.au...
  • Page 4: Kit Contents

    Getting Started DESCRIPTION QUANTITY PARTS SUPPLIED 1 x Right (RF) Front Bracket Assembly 1 x Left (LF) 1 x Right (RM) Middle Bracket Assembly 1 x Left (LM) 1 x Right (RR) Rear Bracket Assembly 1x Left (LR) Socket Head Bolt 12 x M10 Spring Washer 12 x M10...
  • Page 5: Before You Start

    Remove all metal swarf and dust from all vehicle surfaces before proceeding. IMPORTANT Clearview recommends that installation of the Power Boards be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. The installation will take approximately 3 hours.
  • Page 6: Fitting Instructions

    Fitting Instructions IMPORTANT Clearview recommends this to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. The following instruction is for installation of the right-hand side Power Board. Follow same instruction for installation of left-hand side Power Board.
  • Page 7 Unplug black plug behind the gateway (Fig.1) Figure 1 - Black PX3 Gateway Plug Figure 2 - Clearview PX3 wire harness and plug in Clearview PX3 wire harness as in Fig.2 and Fig.3 Plug the Clearview OBD wire harness into the PX3 wire harness (Fig.4) and connect...
  • Page 8 RR Bracket Assembly and motor brackets later. IMPORTANT Align straight-edge tool with the flat edge on the mounting brackets (not the vehicle body) Clearview recommends a straight-edge tool used when mounting mounting brackets. This provides a guide to keeping them level and straight alongside the vehicle.
  • Page 9 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding connectors on the motor wire harness. Passenger (left) Driver (right) side side motor wiring motor wiring Passenger side wires are: Green / Yellow, and Driver side wires are: Blue Route RM (Right-Middle) Driver-side motor wire under the...
  • Page 10 5.3 In some cases, the 'U shape' packing washers may need to be placed in between the front side of the bracket assembly and vehicle bracket mounting points to correctly position Clearview Power Boards. In these few instances, the M8 bolts used to hold top bracket to vehicle will need to be loosened to insert the 'U shape' washer.
  • Page 11: Operation Of Clearview Power Boards

    Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed. To reset, open and close your vehicle door again.
  • Page 12: Maintenance

    Caring for your Clearview Power Boards Whilst the motors don’t require maintenance, regular routine cleaning will help ensure the continued smooth operation of your Clearview Power Boards. Using a garden hose, rinse away any loose dirt and grime that has built up on the Power Boards, their arms, and the areas around them.
  • Page 13: Faqs

    FAQS: Can I perform the installation myself? I already have something plugged into my We recommend installation to be completed OBD-II port, where am I going to plug the by professionals, as there is electrical wiring Power Board harness to if it uses the OBD-II involved, as well as removal of vehicle trims.
  • Page 14: Warranty

    A receipt will be required to make a warranty claim on any Clearview® product. If we determine that a Clearview® Power Board is defective in materials or workmanship during the Warranty, we will either repair or replace the product. Repair or replacement is solely at the discretion of Clearview Accessories®.
  • Page 15: Our Range

    Our Range Towing Mirrors Power Boards Rock Tamers Tyre Spider Power Slides Easy Slides Expanda Slides Fridge Cage Pantry Cutlery Set Clip on Trays Cable Saver clearviewaccessories.com.au...
  • Page 16 Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 info@clearviewaccessories.com.au clearviewaccessories.com.au...
