- Page 1 PB-TA-003 CLEARVIEW® POWER BOARDS ELECTRIC SIDE STEPS * To suit 76 Series Wagon only, will not fit single cab or 79 Series models. (For 79 Series refer to PB-TA-004) TOYOTA LAND CRUISER 76 SERIES 1984 - CURRENT POWER BOARDS INSTALLATION GUIDE...
-
Page 2: Introduction
Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au... -
Page 3: Table Of Contents
Contents Introduction Kit Contents Before You Start Fitting Instructions 6-12 Operation of Clearview Power Boards Maintenance FAQS Warranty Range Guide clearviewaccessories.com.au... -
Page 4: Kit Contents
Kit Contents DESCRIPTION QUANTITY PARTS SUPPLIED 1 x Right (RF) Front Bracket Assembly 1 x Left (LF) 1 x Right (RR) Rear Bracket Assembly 1x Left (LR) 2 x M8 Socket Head T Bolts 4 x M6 Hex Head (40mm) Socket/Hex Head Bolt 8 x M6 Hex Head (25mm) 8 x M6 Socket Head (25mm Black) -
Page 5: Before You Start
IMPORTANT Clearview recommends installation of the Power Boards to be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. The installation should take approximately 3-4 hours. Incorrect installation may cause damage to your vehicle and possible personal injuries. -
Page 6: Fitting Instructions
Fitting Instructions IMPORTANT Clearview recommends this installation to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. Control unit and wiring reference Sensor Wire Harness Door Harness LF/LR & RF/RR Positive Wire... - Page 7 Fitting Instructions IMPORTANT Clearview recommends this installation to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. Step 1 Removal of interior trim and routing of wiring Remove Driver-side interior trim underneath in footwell area:...
- Page 8 Fitting Instructions 1.4 Route RF (Right Front) & RR (Right Rear) door sensor wires along the sill channel to each connector behind the B pillar and C pillar. Expose door switch sensor connectors and connect into rear of door switches. Route RR door sensors Front of vehicle >>...
- Page 9 Fitting Instructions IMPORTANT Clearview recommends this installation to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. NB: The following instruction is for installation of the Right-Hand Side Power Board. Follow same instruction for installation of the Left-Hand Side Power Board.
- Page 10 Fitting Instructions IMPORTANT Align straight-edge tool with the flat edge on Clearview recommends a straight-edge the mounting brackets (not the vehicle body) tool to be used when mounting the top mounting brackets. This provides a guide to keeping them level and straight alongside the vehicle.
- Page 11 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding connectors on the Passenger (left) Driver (right) side motor wire harness. side motor wiring motor wiring Passenger side wires are: Green / Yellow, and Driver side wires are: Blue Route RF (Right-Front) Driver-side motor wire and R-LED...
- Page 12 5.3 In some cases, the ‘U Shape’ packing washers may need to be placed in between the front side of the bracket assembly and vehicle bracket mounting points to position the Clearview Power Boards correctly. In these few instances, the M8 bolts used to hold the mounting bracket to vehicle will need to be loosened to insert the ‘U Shape’...
-
Page 13: Operation Of Clearview Power Boards
To do this, open vehicle door first so Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed. To reset, open and close your vehicle door again. -
Page 14: Maintenance
Caring for your Clearview Power Boards Whilst the motors don’t require maintenance, regular routine cleaning will help ensure the continued smooth operation of your Clearview Power Boards. Using a garden hose, rinse away any loose dirt and grime that has built up on the Power Boards, their arms, and the areas around them. -
Page 15: Faqs
FAQS: Can I perform the installation myself? I already have something plugged into my We recommend installation to be completed OBD-II port, where am I going to plug the by professionals, as there is electrical wiring Power Board harness to if it uses the OBD-II involved, as well as removal of vehicle trims. -
Page 16: Warranty
A receipt will be required to make a warranty claim on any Clearview® product. If we determine that a Clearview® Power Board is defective in materials or workmanship during the Warranty, we will either repair or replace the product. Repair or replacement is solely at the discretion of Clearview Accessories®. -
Page 17: Range Guide
Our Range Warranty Towing Mirrors Power Boards Rock Tamers Tyre Spider Power Slides Easy Slides Expanda Slides Fridge Cage Cutlery Set Pantry Clip on Trays Cable Saver clearviewaccessories.com.au... - Page 20 Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 info@clearviewaccessories.com.au clearviewaccessories.com.au...
