- Page 1 PB-TA-006 TOYOTA LANDCRUISER 300 SERIES 2022-CURRENT POWER BOARDS INSTALLATION INSTRUCTIONS VERSION 1...
- Page 2 Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au...
- Page 3 Contents Introduction Kit Contents Before You Start 6-13 Fitting Instructions Operation of Clearview Power Boards FAQS Warranty Our range clearviewaccessories.com.au...
-
Page 4: Kit Contents
Kit Contents DESCRIPTION QUANTITY PARTS SUPPLIED 1 x Right (RF) Front Bracket Assembly 1 x Left (LF) 1 x Right (RM) Middle Bracket Assembly 1 x Left (LM) 1 x Right (RR) Rear Bracket Assembly 1x Left (LR) 4 x M8 Socket Head T Bolts Socket/Hex Head Bolt 12 x M6 Hex Head (25mm) Plastic Retainer... -
Page 5: Before You Start
Before You Start IMPORTANT Clearview recommends installation of the Power Boards to be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. The installation should take approximately 3 hours. WARNING CAUTION Read through the fitting instructions before installation of Clearview Accessories. -
Page 6: Fitting Instructions
Fitting Instructions Step 1 Installation of wiring Sensor Wire Harness Positive Wire Motor Wire Harness Negative Wire Passenger (left) side Door Harness motor wiring Connector for RM motor Passenger (right) side motor wiring 1.1 Remove LHS Passenger interior trim underneath glovebox and unplug wiring connected to the trim. - Page 7 Fitting Instructions 1.3 Remove the fuse from the positive (red) wire supplied and connect the wire to the vehicle battery positive terminal. Ensure that the connection is secure. 1.4 Feed the positive wire through the vehicle firewall into the passenger (left) side of the vehicle cabin. A plastic wire feeder may be required for this step and subsequent steps.
- Page 8 Fitting Instructions 1.7 Route RF (Right Front) & RR (Right Rear) door sensor wires along the sill channel to each connector behind B pillar and C pillar. REPEAT above steps for LF (Left Front) and LR (Left Rear) door sensor wires. 1.8 Connect each door sensor to the connectors.
- Page 9 Fitting Instructions Step 2 Installing control unit and wiring 2.1 Mount control unit in the passenger kick panel area. The control unit should not be placed in the vehicle engine bay, as exposure to heat and moisture may cause damage to the unit.
- Page 10 Fitting Instructions Step 3 Installing mounting brackets to vehicle 3.1 Locate and remove the factory rubber grommets found along the vehicle's LHS (Left Hand Side) sill rail. 3.2 Feed M8 T Bolts through the opening found on the vehicle sill rail, so that the T section is on the inside of the rail and thread is exposed on the outside of the rail.
- Page 11 Fitting Instructions 3.4 Mount RF (Right Front), RM (Right Middle) & RR (Right Rear) brackets to the underbody of the vehicle/Vehicle Sill Panel using supplied hardware (nuts, bolts and washers). 3.5 It is recommended to line up with a straight-edge tool/object to help with mounting the top mounting brackets.
- Page 12 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding Passenger (left) connectors on motor wire harness. side motor wiring Passenger side wires are green / yellow, and Driver side wires are / blue. Route the RM driver-side motor wire Connector for RM Motor under the vehicle dash and bring across...
- Page 13 (M6 & M8 bolts) once position is finalised. 5.3 In some cases, the 'U shape' packing washers may need to be placed in between bracket assembly and vehicle bracket mounting points to correctly position Clearview Power Boards.
- Page 14 To do this, open vehicle door first so Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed. To reset, open and close your vehicle door again.
- Page 15 FAQS Can I perform the installation myself? I already have something plugged into my We recommend installation to be completed OBD-II port, where am I going to plug the by professionals, as there is electrical wiring Power Board harness to if it also uses the OBD- involved, as well as removal of vehicle trims.
-
Page 16: Warranty
A receipt will be required to make a warranty claim on any Clearview® product. If we determine that a Clearview® Power Board is defective in materials or workmanship during the Warranty, we will either repair or replace the product. Repair or replacement is solely at the discretion of Clearview Accessories®. - Page 17 Our Range Towing Mirrors Power Boards Rock Tamers Tyre Spider Power Slides Easy Slides Expanda Slides Fridge Cage Cutlery Set Pantry Clip on Trays Cable Saver clearviewaccessories.com.au...
