- Page 1 THE AUTO-FOLD MIRROR MODULE TO SUIT ISUZU D-MAX 2012-2019 ISUZU MU-X 2013-2020 AFM-IUDX12-01 INSTALLATION GUIDE Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 | info@clearviewaccessories.com.au clearviewaccessories.com.au VERSION 2.0...
-
Page 2: Getting Started
For detailed instructions on installing Clearview Towing Mirrors, please refer to: https://www.clearviewaccessories.com.au/installation_instructions/ Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. FOR TECHNICAL SUPPORT CALL 03 8351 9933... -
Page 3: Before You Start
Before you Start WARNING CAUTION Read through the fitting instructions before installation of Clearview Accessories. Always install the accessory following the fitting instructions. Failure to do so may cause damage to the vehicle or the accessory. Ensure all recyclable discarded vehicle accessory components and packaging are recycled following local recycling regulations. - Page 4 Unclip the clips behind B and C and also the additional clip on the passenger side of the steering wheel and fold the panel down, then push out the mirror switch panel. Connecting the Clearview Auto-Fold Module (AFM) Step 2...
- Page 5 Fitting Instructions Step 3 Remove the driver side scuff panels Remove the driver-side scuff plate ‘D’ AND the driver-side Remove driver-side kick panel ‘E’ kick panel demonstrated. Feed cables with 2 small connectors Feed the cable with the 2 behind the kick panel small connectors behind this kick panel.
-
Page 6: Operation And Testing
Test operation and return any dash or trim panels back into their original position. Congratulations! You have now fully installed your new Clearview Auto Fold Mirror Module and are ready for your next adventure!
