- Page 1 CLEARVIEW® POWER BOARDS ELECTRIC SIDE STEPS PB-IU-003 ISUZU D-MAX | MY2021 - CURRENT MAZDA BT-50 | MY2020 - CURRENT POWER BOARDS INSTALLATION GUIDE VERSION 2.1...
- Page 2 Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au...
- Page 3 Contents Introduction Kit Contents Before You Start Fitting Instructions 6-11 Operation of Clearview Power Boards Maintenance FAQS Warranty clearviewaccessories.com.au...
-
Page 4: Kit Contents
Kit Contents DESCRIPTION QUANTITY PARTS SUPPLIED 1 x Right (RF) Front Bracket Assembly 1 x Left (LF) 1 x Right (RM) Middle Bracket Assembly 1 x Left (LM) 1 x Right (RR) Rear Bracket Assembly 1x Left (LR) M6 Hex Head Bolt (25mm) 12 x M6 Rubber Grommet (45mm) Spring Washer... -
Page 5: Before You Start
Remove all metal swarf and dust from all vehicle surfaces if the surface is used for accessory installation. IMPORTANT Clearview recommends installation of the Power Boards to be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. -
Page 6: Fitting Instructions
Fitting Instructions Step 1 Installation of wiring 1.1 Remove LHS Passenger front + rear door sill panels and LHS Passenger front kick panel. 1.2 REPEAT on RHS / Drivers side. 1.3 Remove the fuse from the Positive (Red) wire supplied and connect the wire to the vehicle battery Positive... - Page 7 Fitting Instructions 1.5 Route RF (Right Front) & RR (Right Rear) door sensor wires along the sill channel to each connector behind the B pillar and C pillar. Remove door trigger sensors REPEAT above steps for LF (Left Front) and LR (Left Rear) door sensor wires.
- Page 8 Fitting Instructions Step 3 Installing mounting brackets to vehicle 3.1 Locate and remove the factory grommets underneath the vehicle's LHS (Left Hand Side) as shown on in example below. 3.2 With the 45mm Rubber Grommet supplied in kit, cut a cross pattern in middle of grommet to allow wiring to be passed through.
- Page 9 3.4 Mount RF (Right Front), RM (Right Middle) & RR (Right Rear) brackets to the underbody of the vehicle/Vehicle Sill Panel using supplied hardware (nuts, bolts and washers). IMPORTANT Clearview recommend a straight-edge tool to be used when mounting the top mounting brackets. This provides a guide to keeping them level and straight alongside the vehicle.
- Page 10 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding Passenger (left) connectors on motor wire harness. side motor wiring Passenger side wires are green / yellow, and Driver side wires are / blue. Route the RM driver-side motor wire Connector for RM Motor under the vehicle dash and bring across...
- Page 11 5.3 In some cases, the 'U shape' packing washers may need to be placed in between the front side of the bracket assembly and vehicle bracket mounting points to correctly position Clearview Power Boards. In these few instances, the M8 bolts used to hold top bracket to vehicle will need to be loosened to insert the 'U shape' washer.
- Page 12 To do this, open vehicle door first so Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed.
-
Page 13: Maintenance
Caring for your Clearview Power Boards Whilst the motors don’t require maintenance, regular routine cleaning will help ensure the continued smooth operation of your Clearview Power Boards. Using a garden hose, rinse away any loose dirt and grime that has built up on the Power Boards, their arms, and the areas around them. - Page 14 Can I perform the installation myself? I already have something plugged into my We recommend installation to be completed OBD-II port, where am I going to plug the by professionals, as there is electrical wiring Power Board harness to if it also uses the OBD- involved, as well as removal of vehicle trims.
-
Page 15: Warranty
A receipt will be required to make a warranty claim on any Clearview® product. If we determine that a Clearview® Power Board is defective in materials or workmanship during the Warranty, we will either repair or replace the product. Repair or replacement is solely at the discretion of Clearview Accessories®. - Page 16 Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 info@clearviewaccessories.com.au clearviewaccessories.com.au...
