- Page 1 CLEARVIEW® POWER BOARDS ELECTRIC SIDE STEPS TO SUIT: NISSAN PATROL Y62 2013 - CURRENT PB-NN-003 INSTALLATION GUIDE Clearview Accessories 3 Frog Court, Craigieburn VIC 3064 (03) 8351 9933 | info@clearviewaccessories.com.au clearviewaccessories.com.au VERSION 2.0 NOV 2023...
- Page 2 Phone: (03) 8351 9933 Email: info@clearviewaccessories.com.au Website: clearviewaccessories.com.au Find us on social media facebook.com/clearviewaccessories instagram.com/clearviewaccessories youtube.com/clearviewaccessories Due to Clearview's Continuous Improvement Program, information may change without notice. Clearview takes no responsibility for the result of incorrect use of these installation instructions. clearviewaccessories.com.au...
- Page 3 Contents Introduction Kit Contents Before You Start 6-10 Fitting Instructions Operation of Clearview Power Boards FAQS Warranty Our range clearviewaccessories.com.au...
-
Page 4: Kit Contents
Power Boards will revolutionise your travel experience. Clearview Power Boards are triggered by the vehicle’s door sensor, so when the door opens, they drop to a convenient stepping height and when the door closes, they retract. With 300kg load capacity, safety cut off feature and IP68 rating on the motors, accessing your vehicle is as easy as one step up. -
Page 5: Before You Start
IMPORTANT Clearview recommends installation of the Power Boards to be performed by a professional as installation will require vehicle trim removal, wire routing and electrical work. The installation should take approximately 3 hours. Incorrect installation may cause damage to your vehicle and possible personal injuries. -
Page 6: Fitting Instructions
Step 1 Removal of interior trim and routing of wiring IMPORTANT Clearview recommends this to be completed by a professional. Incorrect installation may cause damage to your vehicle and possible personal injuries. Remove Driver-side interior trim underneath in Remove kick panel footwell area: Un-clip the door sill panels and the kick panel trim. - Page 7 Fitting Instructions 1.4 Route RF (Right Front) & RR (Right Rear) door sensor wires along the sill channel to each connector behind the B pillar and C pillar. Expose door switch sensor connectors and connect into rear of door switches. Remove door Route RR door sensors Front of vehicle...
- Page 8 2 x M8 Bolt (1 Hex, 1 Socket) tightened. 2 x M8 Flat Washer 2 x M8 Spring Washer IMPORTANT Clearview recommends a straight-edge Align straight-edge tool with the tool to be used when mounting the top flat edge on the mounting mounting brackets.
- Page 9 Fitting Instructions Step 4 Connecting Power to the motor brackets 4.1 Connect motor wires to corresponding Passenger side (left) Connector for LM Motor connectors on motor wire harness. motor wiring Passenger side wires are green / yellow, and Driver side wires are / blue.
- Page 10 5.3 In some cases, the 'U shape' packing washers may need to be placed in between the front side of the bracket assembly and vehicle bracket mounting points to correctly position Clearview Power Boards. In these few instances, the M8 bolts used to hold top bracket to vehicle will need to be loosened to insert the 'U shape' washer.
- Page 11 To do this, open vehicle door first so Clearview Power Boards are deployed. Step your foot on the running board and close your vehicle door at the same time, the Clearview Power Board should remain deployed. To reset, open and close your vehicle door again.
- Page 12 Can I perform the installation myself? I already have something plugged into my We recommend installation to be completed OBD-II port, where am I going to plug the by professionals, as there is electrical wiring Power Board harness to if it also uses the OBD- involved, as well as removal of vehicle trims.
-
Page 13: Warranty
In the event of a minor failure, the company reserves the right to choose to repair or replace the product. Clearview Towing Mirrors | ABN: 59 140 145 393 | 3 Frog Court, Craigieburn VIC 3064 Ph: (03) 8351 9933 | Email: info@clearviewaccessories.com.au... - Page 14 Our Range Towing Mirrors Power Boards Rock Tamers Tyre Spider Power Slides Easy Slides Expanda Slides Fridge Cage Cutlery Set Pantry Clip on Trays Cable Saver clearviewaccessories.com.au...
