Wired controller - SAVA X
EN
INSTALLATION METHOD
For some units, the wired controller connects to the unit HA and HB ports through the
HA and HB ports. There is no polarity between HA and HB (see g. 3-9).
Indoor Unit
Wired Controller
Fig. 3-9
The main/secondary wired controller can be used to enable two wired controllers
to control one unit, and the wired controllers connect to the unit HA and HB ports
through the HA and HB port on the controller. There is no polarity between HA and
HB (see g. 3-10).
21
Installation and Owner's Manual
