Wired controller - SAVA X
EN
INSTALLATION METHOD
• Do not pry up and down, you can only rotate the screwdriver.
• The PCB is mounted in the upper part of the wired controller. Be careful not to
damage the board with the slot screwdriver.
3. FASTEN THE BACK PLATE OF THE WIRED CONTROLLER
• For exposed mounting, fasten the back plate on the wall with the 3 screws (ST3.9 x
25) and plugs. (Fig.3-3)
Back plate
14
Installation and Owner's Manual
NOTE
Fig. 3-3
Screws (ST3.9 x 25)
