Wired controller - SAVA X
EN
INSTALLATION METHOD
• Use two M4X25 screws to install the back cover on the 86 switch box, and use one
ST3.9 x 25 screw to x to the wall.
Screw hole xed on the wall,use one ST3,9 x 25mm
Screw hole installed on 86 switch box, use two M4X25mm
Fig. 3-4
NOTE
Put on a at surface. Be careful not to distort the back plate of the wire controller
by overtightening the mounting screws.
15
