Wired controller - SAVA X
EN
INSTALLATION ACCESSORY
1. SELECT THE INSTALLATION LOCATION
Don't install at the place where cover with heavy oil, vapor or sulfureted gas, otherwise,
this product would be deformed that would lead to system malfunction.
2. PREPARATION BEFORE INSTALLATION
No. Name
1 Wire controller
Installation and owner's
2
manual
3 Screws
4 Wall plugs
5 Screws
6 Plastic screw bars
7 Battery
The connective wires
8
group
9 Screws
10
Installation and Owner's Manual
Qty.
1
1
3 M3.9 x 25 (For Mounting on the Wall)
3 For Mounting on the Wall
2 M4X25 (For Mounting on switch box)
2 For xing on switch box
1
1
M4X8 (For Mounting the connective
1
Remarks
-
-
-
Optional
wire group)
