Correct Installation - OPT7 AURA PRO WITH SOUNDSYNC Installation Manual

BE SURE TO CONFIRM THE CORRECT DIRECTION OF THE ARROW!!
TO AVOID PRODUCT DAMAGE DUE TO INCORRECT INSTALLATION.

CORRECT INSTALLATION

Connecting to more than 10 AMP will override the kit and cause early failure,
1.
ensure it is 10 AMP or less!!
2
Please ensure that the LED bars or strips/control box/wiring all are mounted in
WARNING
areas where will not exceed 85℃ or 185℉.
3.
Connect only to a 12V battery. Using other voltages may cause overload and
serious safety risks.
IMPORTANT
INSTALLATION
IMPORTANT
!
Flow direction
*Turning off the OPT7 GLOW completely helps avoid excessive
battery consumption and extends the lifespan of the OPT7 light kits.
Secure Control box in desired location
with Velcro or zip ties.
* CONTROL BOX NOT WATERPROOF
Ensure the control box is safely and securely hidden
from exposing elements of moisture.
Mount brackets to secure the
strip first.
!
Note the
direction of
the arrows
STEP 2
STEP 3
