GRILLE

BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED

INSTALLATION GUIDE

COMPONENTS

LED LIGHT STRIPS

EXTENSION WIRES

OFF

AUTO

S+

M+

S-

M-

AURA CONTROL BOX (SCAN QR CODE FOR APP USER GUIDE)

HARDWIRE POWER HARNESS

HAND HELD REMOTE

MOUNTING KIT

Need help?

Do you have a question about the AURA PRO and is the answer not in the manual?

Page 1 GRILLE BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED INSTALLATION GUIDE COMPONENTS LED LIGHT STRIPS EXTENSION WIRES AUTO AURA CONTROL BOX (SCAN QR CODE FOR APP USER GUIDE) HARDWIRE POWER HARNESS HAND HELD REMOTE MOUNTING KIT...
Page 2 Please ensure that the LED bars or strips/control box/wiring all are mounted WARNING in areas where will not exceed 85℃ or 185℉. *Turning oﬀ the OPT7 GLOW completely helps avoid excessive IMPORTANT battery consumption and extends the lifespan of the OPT7 light kits.
Page 3 IMPORTANT BE SURE TO CONFIRM THE CORRECT DIRECTION OF THE ARROW!! TO AVOID PRODUCT DAMAGE DUE TO INCORRECT INSTALLATION. Flow direction Note the direction of the arrows CORRECT INSTALLATION STEP 3 Oﬀ AUTO Using the included 21Key E-Z Remote, select your desired color or pattern.
Page 4 Please scan to see the OPT7 GLOW user guide. https://wintis.ladesk.com/362302-OPT7-AURA-Glow-Application-User-Guide DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation.
