- Page 1 AURA PRO UNDERGLOW BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED RV CLASS B/B+ FIT INSTALLATION GUIDE RV Class B : 19~23 ft RV Class B+: 19~24 ft RV Class B : 10 ft RV Class B+: 11 ft AURA PRO...
-
Page 2: Installation
COMPONENTS COMPONENTS 8ft EXTENSION WIRE RIGID LIGHT BARS 2×48'' (TWO-SECTION MOVABLE 24") + AUTO 8ft EXTENSION WIRE RIGID LIGHT BARS 1×36'' (TWO-SECTION MOVABLE 18") + HAND HELD REMOTE 8ft EXTENSION WIRE RIGID LIGHT BARS 3×36'' (TWO-SECTION MOVABLE 18") + 1 HARDWIRE POWER HARNESS AURA PRO BLUETOOTH CONTROL BOX (SCAN QR CODE FOR APP USER GUIDE) -
Page 3: Control Box
STEP 2 IMPORTANT The control box is waterproof, but it should still be Decide where to locate the control box and installed in a safe area of the vehicle. Please avoid ensure wiring has enough length for light bars to installing it in the engine bay or on heated surfaces. - Page 4 EXAMPLES Y-SPLITTER FUSE EXTENSION WIRE Y-SPLITTER The extension wires are on the led bar. Lay out the bars to measure the length prior to install for a successful installation. 1 x 36” (two-section movable 18") LED Bar + 8ft extension wire 1 x 48”...
-
Page 5: Correct Installation
IMPORTANT BE SURE TO CONFIRM THE CORRECT DIRECTION OF THE ARROW!! TO AVOID PRODUCT DAMAGE DUE TO INCORRECT INSTALLATION. Flow direction Note the direction of the arrows CORRECT INSTALLATION STEP 3 Secure Control box in desired location with Velcro or zipties. *Ensure the control box is mounted away from water and heated metal surfaces for optimal performance. - Page 6 Download the free “OPT7 GLOW” App • App iOS (12+) available on App Store • Android (8+) available on Google Play Please scan to see the OPT7 GLOW user guide. https://wintis.ladesk.com/362302-OPT7-AURA-Glow-Application-User-Guide OPTION METHOOD To power the kit using an switched 10 AMP fuse tap method, you may purchase the AURA Universal Replacement Fuse Tap Adapter Set &...
- Page 7 DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation. If you are unfamiliar with your vehicle or inexperienced with aftermarket upgrades, please seek professional assistance.
