AURA PRO

DRL HALO RGB

FORD MUSTANG 05-14

BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED

COMPONENTS

OFF

AUTO

S+

M+

EXTENSION WIRES

LED LIGHT STRIPS

S-

M-

AURA Control Box (SCAN QR CODE FOR APP USER GUIDE)

HAND HELD REMOTE

MOUNTING KIT

HARDWIRE POWER HARNESS

ZIP TIES

Need help?

Do you have a question about the AURA PRO and is the answer not in the manual?

Page 1 AURA PRO DRL HALO RGB FORD MUSTANG 05-14 BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED COMPONENTS AUTO EXTENSION WIRES LED LIGHT STRIPS AURA Control Box (SCAN QR CODE FOR APP USER GUIDE) HAND HELD REMOTE MOUNTING KIT HARDWIRE POWER HARNESS...
Page 2: Installation
INSTALLATION STEP 3 STEP 1 Remove the plastic covers on the right Open the hood. and left side of the engine bay. STEP 4 STEP 2 Run the wires along the front brace and Wrap the LED strip into a circle shape connect to the control box.
Page 3: Correct Installation
Please ensure that the LED bars or strips/control box/wiring all are WARNING mounted in areas where will not exceed 85℃ or 185℉. *Turning oﬀ the OPT7 GLOW completely helps avoid excessive IMPORTANT battery consumption and extends the lifespan of the OPT7 light kits.
Page 4 INSTALLATION STEP 6 Oﬀ AUTO Using the included 21Key E-Z Remote, select your desired color or pattern. Power-ON Automatic Color Change Power-OFF Speed +/- 10 evels Mode +/- 24 Mode Dimmer 10 Levels Color Selection 12 Colors NOTE: When you use this product, keep it within 10m/33ft as much as possible.
Page 5 Please scan to see the OPT7 GLOW user guide. https://wintis.ladesk.com/362302-OPT7-AURA-Glow-Application-User-Guide DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation.
