- Page 1 GRILLE INSTALLATION GUIDE MAIN COMPONENTS 12'' LIGHT STRIPS MOUNTING KIT AURA CONTROL BOX REMOTE FUSE TAPS CIGARETTE LIGHTER POWER ADAPTER EXTENSION WIRES POWER HARNESS V1.1.062719...
- Page 2 INSTALLATION STEP 1 Decide where to locate the light strips and ensure wiring has enough length for control box to be installed in desired location. As shown below, connect all light pods to the control box with the included extension cables. AUXILIARY WIRE EXTENSION WIRE Once connected, plug the control box Cigarette Power Adapter into an available...
- Page 3 AUX WIRING FOR A DOME/DOOR LIGHT NOTE: This feature activates white light only. In order to activate Door Assist Sync, you need to connect the aux wiring of Aura control box to the positive and negative wiring of dome or door light.
- Page 4 OPTIONAL UPGRADE Upgrade your Aura Original Control Box to the Aura Pro Bluetooth Control Box. All new AURA Pro Bluetooth is App enabled by a smartphone controller (iOS & Android Compatible). AURA PRO BLUETOOTH CONTROL BOX CONNECTED WHITE DOOR RANDOM...
