WITH
SOUNDSYNC
BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED
GOLF CART
INSTALLATION GUIDE
COMPONENTS
On
Off
AUTO
S+
M+
LED LIGHT STRIPS WITH EXTENSION WIRE
S-
M-
1
2
3
AURA CONTROL BOX (SCAN QR CODE FOR APP USER GUIDE)
HAND HELD REMOTE
Y-SPLITTERS
MOUNTING KIT
HARDWIRE POERT HARNESS
Advertisement
Related Manuals for OPT7 AURA PRO WITH SOUNDSYNC
Summary of Contents for OPT7 AURA PRO WITH SOUNDSYNC
- Page 1 WITH SOUNDSYNC BLUETOOTH OPT7 GLOW APP & REMOTED CONTROLLED GOLF CART INSTALLATION GUIDE COMPONENTS Off AUTO LED LIGHT STRIPS WITH EXTENSION WIRE AURA CONTROL BOX (SCAN QR CODE FOR APP USER GUIDE) HAND HELD REMOTE Y-SPLITTERS MOUNTING KIT HARDWIRE POERT HARNESS...
- Page 2 INSTALLATION STEP 1 Decide where to locate the control box and ensure wiring has enough length for light bars to be installed in desired location. LEFT LEFT FRONT FRONT REAR REAR RIGHT RIGHT As shown below, connect all the LED bars to the control box with the included extension cables. IMPORTANT: 1 ×...
- Page 3 Connect only to a 12V battery. Using other voltages may cause overload and serious safety risks. *Turning off the OPT7 GLOW completely helps avoid excessive IMPORTANT battery consumption and extends the lifespan of the OPT7 light kits. STEP 2 Secure Control box in desired location with Velcro or zip ties.
- Page 4 STEP 4 Secure the light strips using the zip ties to tie all the wiring away from the moving components. STEP 5 Connect the round connector from the light strips to the control box and ensure that each component is properly installed and tightened. INSTALL CORRECTLY STEP 6 Off...
- Page 5 Please scan to see the OPT7 GLOW user guide. https://wintis.ladesk.com/362302-OPT7-AURA-Glow-Application-User-Guide DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation.
