EGR ROLLTRAC Installation Instructions Manual page 9

LHS MOUNT EXTRUSION ASSEMBLY
SPACER
5
SPACER
SECTION VIEW
8
Check if the plastic spacers are in place, if they have fallen out during transport, please refit.
RHS MOUNT EXTRUSION ASSEMBLY
8
x2
12
12
x2
7
9
Fit the side brackets (7) to the mount extrusion (6) as shown. Do not torque the screws at this stage.
Attention: Fit screws only two rotations into the plates.
RT0082
SPACER
9
6
x2
LOOSE
FIT
SECTION VIEW
5
SPACER
9
12
x2
12
x2
Page 9 of 37
9
8
x2
12
x2
7
Issue 2: 01/08/24
