EGR ROLLTRAC ELECTRIC Installation Instructions Manual

For toyota tundra 5.5ft bed lhd 2022 onwards
Hide thumbs Also See for ROLLTRAC ELECTRIC:

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTIONS
Installation time: 180 minutes
Caution
• Do not attach EGR RollTrac in a location or by a method not specified.
• Do not use this product for any vehicle make or model, other than those specified in this document.
• Do not remove the plaque or label from this product.
• Do not modify the structure of the EGR RollTrac in any way.
General Notes
• Read through the fitting instructions before installation of EGR RollTrac.
• Always install the accessory following the fitting instructions. Failure to do so may cause damage to the vehicle or the accessory.
• Ensure all recyclable discarded vehicle accessory components and packaging are recycled following local recycling regulations.
• It is always recommended that this accessory is fitted by a qualified Technician.
• Safely store and protect any removed vehicle components.
• Ensure all bare metal surfaces are protected using Automotive Bare Metal Primer and touch-up paint.
• Remove all metal swarf and dust from all vehicle surfaces if surface is used for accessory installation.
Safety Notes
• Check that all work practices comply with safety standards.
• Please wear appropriate clothing and use safety equipment.
RT0094
ELECTRIC
Vehicle Model: Toyota Tundra 5.5Ft Bed LHD
Year of manufacture:
2022
onwards
Page 1 of 36
Issue 1: 03/07/24

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROLLTRAC ELECTRIC and is the answer not in the manual?

Questions and answers

Related Manuals for EGR ROLLTRAC ELECTRIC

Summary of Contents for EGR ROLLTRAC ELECTRIC

  • Page 1 Installation time: 180 minutes Caution • Do not attach EGR RollTrac in a location or by a method not specified. • Do not use this product for any vehicle make or model, other than those specified in this document. • Do not remove the plaque or label from this product.
  • Page 2 BED PREP ELECTRICAL START SECTION A SECTION B STEP 1-11 STEP 1-14 EGR RollTrac ASSEMBLY EGR RollTrac SECTION C INSTALLATION STEP 1-11 SECTION D STEP 1-5 OPERATIONS CALIBRATION FINAL NOTES SECTION E FINISH RT0094 Page 2 of 36 Issue 1: 03/07/24...
  • Page 3 KIT CONTENTS - COMPONENT NUMBER AND QUANTITY CANISTER ASM. QTY: 1 FRONT COVER QTY: 1 LHS RAIL QTY: 1 RHS RAIL QTY: 1 HEADERBAR QTY: 1 EGR RollTrac FITTING KIT IN BOX MISC5620PC-RH MISC5421 SCRW0973 MISC5620PC-LH MISC5621 SCREW M6x15 CORNER BRACKET...
  • Page 4 EGR RollTrac FITTING KIT COMPONENTS IN BAGS MAIN HARNESS BLADE FUSES T-PATCH CABLE TIE (200mm) CABLE TIE (500mm) QTY: 30 QTY: 8 EGR RollTrac FITTING KIT ADDITIONAL ITEMS OWNERS MANUAL & INSTALLATION INSTRUCTIONS RUBBER SETTIG BRACE EXTRUSION QTY: 1 QTY: 2...
  • Page 5 SECTION A BED PREPARATION Thoroughly wash the vehicle and bed and ensure that all dirt and grease is removed. Allow to dry. Clean the top surfaces of the bed and tailgate and allow to dry. Carefully remove both Rear Tail Lamps with the appropriate tools and store in safe place.
  • Page 6 Ø29mm (11/8”) HOLE FOR VEHICLE HARNESS LHS ONLY Ø29mm Mark the position for the Vehicle Harness on the LHS of the tub. The distance is 60mm PCD from the drain tube hole. Soapy Water Fit the front drain tubes to the tub. RT0094 Page 6 of 36 Issue 1: 03/07/24...
  • Page 7 Ø29mm (11/8”) 55mm (2.1’’) HOLES FOR REAR DRAIN TUBES RHS & LHS ATTENTION Ensure that the diameter of the hole does not exceed Ø29mm (11/8”) Larger hole size will lead to water ingress into the bed 400mm (15.7”) Mark the position of the rear drain tubes holes in the bed rear panel and drill with holesaw.
  • Page 8 T40 Torx Key Remove and discard the front utility rail. Retain the 7 Torx screws. RHS BED FRONT CORNER FILL GAPS AS REQUIRED T40 Torx Key Silicone DO NOT FIT SCREW DO NOT FIT SCREW Insert the foam block (26) into the gap between tub and bed cap as shown. Silicone the foam block in place. Silicone the gap between the panels as shown on both sides.
  • Page 9 Allen Key 4mm (5/32’’) T40 Torx Key Assemble the corner bracket to the rail using T-Nut (11), screw (6) and torx screw (previously removed) as shown on the RHS. T40 Torx Key Fit rear tub bracket as shown on the RHS. Remove the two torx screws holding the cargo hook and refit with the bracket.
  • Page 10 TAPE0751 TAPE 3x12x500mm QTY: 2 Apply the 3mm EPDM tape to the tub as shown on the RHS and repeat for the LHS. Clean the area with an alcohol wipe. T40 Torx Key TAILGATE NOT SHOWN FOR CLARITY Fit rear tub bracket as shown on the RHS. Use existing hardware to attach the bracket. Use the spacer (12) between the bracket and tub where shown.
  • Page 11 ELECTRICAL LOOM INSTALLATION SECTION B IMPORTANT: DISCONNECT CAR BATTERY NEGATIVE TERMINAL. FIT THE FUSE AT THE END OF INSTALLATION. WHILE ROUTING THE VEHICLE HARNESS AVOID ANY VEHICLE COMPONENTS THAT HEAT UP, SUCH AS EXHAUST AND ENGINE COMPONENTS. DO NOT ATTACH HARNESS TO MOVING PARTS, FUEL LINES, BRAKE LINES, MOVING PARTS AND AVOID PINCH POINTS.
  • Page 12 USE DRAW WIRE TO PULL VEHICLE HARNESS INTO THE ENGINE BAY TUCK THE HARNESS BEHIND THE SHIELDING KEEP CLEAR OF STEERING COLUMN Feed the harness into the engine bay on the LHS along the fire wall from underneath the vehicle. Use draw wire first by pushing it down from the engine bay.
  • Page 13 REAR From underneath the vehicle, route the Vehicle Harness connector C&D towards the rear of the vehicle, following outside the chassis rail. Use the supplied cable ties and retain the harness every 200mm (8’’) to the chassis rail. RUBBER SCUFF PLATE GROMMET Inside the vehicle (LH) side, lift the scuff plate to allow lifting the carpet under the seat in order to expose the rubber grommet in the floor.
  • Page 14 B-PILLAR VIEW MIDDLE PANEL REAR SEATBELT BOLT PLACE WIRING LIFT UNDER THE SCUFF PLATE SCUFF PLATE SCUFF PLATE Lift the rear scuff plate. Remove the middle panel on the B-pillar as shown above. IMPORTANT: Remove the seatbelt bolt in order to remove the middle panel). Place the wiring under the scuff plate and run to the base of the B-pillar.
  • Page 15 T-PATCH Inside the vehicle connect the previously disconnected connector inside the B-pillar to the (F) connector from the T-patch join the connector (G) with the connector outside the B-pillar. Refit the connector on the outside of the B-pillar as shown. RT0094 Page 15 of 36 Issue 1: 03/07/24...
  • Page 16 T-PATCH Inside the vehicle connect the previously disconnected connector inside the B-pillar to the (F) connector from the T-patch join the connector (G) with the connector outside the B-pillar. T-PATCH VEHICLE HARNESS Connect the Vehicle Harness connector C to the T-patch connector E. Push the connectors and the T-patch inside the pillar and use zip ties to secure.
  • Page 17 REAR From underneath the vehicle, route the Vehicle Harness connector D towards the rear of the vehicle, following outside the chassis rail. Use the supplied cable ties and retain the harness every 200mm (8’’) to the chassis rail. GROMMET VEHICLE HARNESS Pull up the connector (C) into the truck bed into the previously drilled hole in the front LHS of the bed, until the rubber grommet sits firmly in the hole.
  • Page 18 HARNESS ROUTING OVERVIEW FOR HYBRID VEHICLE GROMMET NOT USED VEHICLE HARNESS T-PATCH TOP VIEW RT0094 Page 18 of 36 Issue 1: 03/07/24...
  • Page 19 FIT THIS GROMMET TO THE FLOOR HOLE RUBBER SCUFF PLATE GROMMET Inside the vehicle (LH) side, lift the scuff plate to allow lifting the carpet under the seat in order to expose the rubber grommet in the floor. Remove and discard the grommet. Feed the vehicle harness branch (D) into the cabin.
  • Page 20 CLIP PUSH DOWN CONNECTOR Locate the connector on the outside of the B-pillar and disconnect as shown. NOTE: Pull the tab under the rubber boot to remove the boot. T-PATCH Inside the vehicle connect the previously disconnected connector inside the B-pillar to the (F) connector from the T-patch join the connector (G) with the connector outside the B-pillar.
  • Page 21 Refit the connector on the outside of the B-pillar as shown. T-PATCH VEHICLE HARNESS Connect the Vehicle Harness connector C to the T-patch connector E. Push the connectors and the T-patch inside the pillar and use zip ties to secure. Secure the Vehicle Harness to the existing harness all the way down to the floor. RT0094 Page 21 of 36 Issue 1: 03/07/24...
  • Page 22 BATTERY TERMINAL Lift up back seat on drivers side, remove battery cover. Connect the vehicle harness branch (A) to the battery positive terminal. Connect the vehicle harness branch (B) to the negative terminal of the battery. Once it is positioned, secure in place using cable ties. NOTE: ensure fuses are not fitted to the harness.
  • Page 23 GROMMET VEHICLE HARNESS Pull up the connector (C) into the truck bed into the previously drilled hole in the front LHS of the bed, until the rubber grommet sits firmly in the hole. IMPORTANT: use draw wire to pull up the connector. RT0094 Page 23 of 36 Issue 1: 03/07/24...
  • Page 24 EGR RollTrac ASSEMBLY SECTION C DURING ASSEMBLY PROCEDURE SUPPORT AT CENTER OF CANISTER ONLY, PLACE ON TOP AND BASE CARTON (OR SIMILAR), COVER WITH FOAM BLANKET. TO AVOID SCRATCHING POWDERCOATED SURFACES. DO NOT LOAD ELECTRICAL CONNECTORS OR MOTOR COVER. FIT RHS 4mm(5/32’’)
  • Page 25 CAUTION 90° FIT FIRST ALIGN HOLES FIT SECOND SLIDE INTO POSITION ALIGN HOLES INSERT SCREWS AND TIGHTEN LOOSELY GENTLY WIGGLING THE PART INTO THE FINAL TUCK LOOM TO THE SIDE POSITION MAY HELP Pull hand rail to expose 3 slats. Slide the RHS Rail over slat ends and onto endcap location pins. Align the holes and secure loosely with two screws (6).
  • Page 26 REMOVE TAPE SECURING THE RUBBER CORNER SEAL CAUTION DO NOT DAMAGE ATTENTION: Remove foam tape end from the side rail before fitting into front cover Slide the Front Plate (2) over the canister and into the side rail channels ensuring that the foam side rail tape is pulled out of side rail and the small rubber corner seal on the RHS and LHS of the front plate are not damaged.
  • Page 27 5.5Nm (4ft-lb) 4mm(5/32’’) INSERT SCREWS AND TORQUE TO 5.5Nm (ff-lb) REAR VIEW Using 3 screws (6), secure the Front Plate (2) to the Canister Assembly (1) and torque to 5.5Nm (4ft-lb). 5.5Nm (4ft-lb) 4mm(5/32’’) SIDE VIEW Carefully flip the assembly over onto a flat protected surface which will not damage the cover or scratch the paint work.
  • Page 28 LHS SHOWN - RHS IS A MIRROR IMAGE CLEAN WITH ALCOHOL FIRST TAPE TAPES MUST CONTACT Clean powder coated surface first with alcohol spray. Trim foam tape length to ensure the end will butt against front cover seal - avoiding any gap. Peel the protective liner from the foam tape, adhere to the channel in the side rail, Press down firmly to secure.
  • Page 29 CONNECT PUSH CLICK PULL CONNECT PUSH CLICK PULL SECURE ALL CABLES TO PREVENT PINCHING Connect side rail harness connectors to the connectors on the canister on the LHS and RHS. Connect the lamp connector as shown next to the motor on the RHS. Secure the harness to the canister using cable ties and pads as shown.
  • Page 30 SECTION D EGR RollTrac INSTALLATION SETTING BRACE - USER GUIDE • NOT TO BE USED AS LIFTING DEVICE • DIAGONAL MEASUREMENTS ARE REQUIRED AS PER THE FITTING INSTRUCTIONS • SETTING BRACE SHOULD BE REMOVED ONLY WHEN SET UP IS COMPLETED Setting Brace comes assembled.
  • Page 31 FOR SETTING BRACE USE, PLEASE REFER TO THE “SETTING BRACE - USER GUIDE” SIDE RAIL TAILGATE CENTRALISE AND ALIGN THE COVER TO THE MARKINGS FRONT SEAL 27mm TAILGATE COVER POSITION REARWARDS Apply masking tape at the centre of the tailgate. Measure the distance between the rear corners of the tub and draw a centre line on the masking tape.
  • Page 32 METRIC Tape Measure PERFORM FITMENT CHECK Perform diagonal fitment check. 5.5Nm VIEW UNDER THE BASE RAIL RHS BOLT TIGHTENING SEQUENCE Fit the x3 side rail brackets and the rear tub bracket (19) to the base rails with screws (23) as shown in top detail. Torque the screws following the sequence in the detail.
  • Page 33 SILICONE SPRAY Close the inspection covers and secure with retained screws. Open and close the EGR RollTrac to distribute lubricant and check operation. Allen Key 4mm INSPECTION COVER...
  • Page 34 WARNING: Keep obstructions clear of cover during calibration mode. 5 SECONDS PULL • Cover will CLOSE and OPEN once automatically. • The EGR RollTrac internal LED light will pulse slowly during calibration and stop pulsing when calibration is complete. 2 SECOND PULSE START OF CALIBRATION...
  • Page 35 NOTE: EGR RollTrac should open and close smoothly. If cover does not lock or open correctly, please refer to the trouble shooting section in the Owners Manual. If the EGR RollTrac closing is slow, clean the siderails and ensure that no dirt or debris is inside the drive rail.
  • Page 36 KEY FOB OPERATION IMPORTANT: We recommend that you program your key fob to lock and unlock all doors using one click only. This function can be set on your infotainment screen using the vehicle system control function/setup: SETTINGS (icon) VEHICLE REMOTE LOCK, UNLOCK.
