EGR ROLLTRAC Installation Instructions Manual

Ford f-150 6.5ft bed rhd&lhd - compatible with boxlink 2018 onwards
Hide thumbs Also See for ROLLTRAC:

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTIONS
Vehicle Model: Ford F-150 6.5Ft Bed RHD&LHD - Compatible with Boxlink®
Year of manufacture:
Part Number: RT040032E
FORD AU P/N: AMNL3J501A34BA
Installation time: 180 minutes
Caution
• Do not attach EGR RollTrac in a location or by a method not specified.
• Do not use this product for any vehicle make or model, other than those specified in this document.
• Do not remove the plaque or label from this product.
• Do not modify the structure of the EGR RollTrac in any way.
General Notes
• Read through the fitting instructions before installation of EGR RollTrac.
• Always install the accessory following the fitting instructions. Failure to do so may cause damage to the vehicle or the accessory.
• Ensure all recyclable discarded vehicle accessory components and packaging are recycled following local recycling regulations.
• It is always recommended that this accessory is fitted by a qualified Technician.
• Safely store and protect any removed vehicle components.
• Ensure all bare metal surfaces are protected using Automotive Bare Metal Primer and touch-up paint.
• Remove all metal swarf and dust from all vehicle surfaces if surface is used for accessory installation.
Safety Notes
• Check that all work practices comply with safety standards.
• Please wear appropriate clothing and use safety equipment.
RT0082
ELECTRIC
2018
onwards
Page 1 of 37
*RT0082*
Issue 2: 01/08/24
