EGR ROLLTRAC Installation Instructions Manual page 11

Ford f-150 6.5ft bed rhd&lhd - compatible with boxlink 2018 onwards

Hide thumbs Also See for ROLLTRAC:

Note: Trucks without factory supplied cargo hooks may need to be threaded/tapped M6xPitch:1.0

Hold the assembly in position and fit screws (12). Do not torque the screws.

LHS

Fit the setup jigs, to set up the RH mount extrusion first. Adjust the mount extrusion front position to the bed cap and

rear position to the top of the tailgate using the setup jigs as a guide.

RT0082

Page 11 of 37

RHS

Issue 2: 01/08/24
