EGR ROLLTRAC Installation Instructions Manual page 3

1
CANISTER ASM. QTY: 1
3
LHS RAIL QTY: 1
5
LHS MOUNT EXTRUSION QTY: 1
7
CLIP3989PC
SIDE BRACKET
QTY: 4
12
SCRW0997
SCREW M6x20
QTY: 36
13
KIT037458
REAR DRAINAGE TUBE
QTY: 2
17
SCRW0997
SCREW M6x20
QTY: 2
RT0082
KIT CONTENTS - COMPONENT NUMBER AND QUANTITY
EGR RollTrac M-Bar Assy Hardware Kit
8
MISC5512
REAR BRACKET
QTY: 8
EGR RollTrac FITTING KIT IN BOX
18
CONS70097
CABLE TIE
QTY: 10
2
4
6
9 10
MISC5622
CLAMP PLATE
QTY: 6
14
MISC5222
FRONT DRAINAGE TUBE
QTY: 2
SETTING BRACE
Page 3 of 37
FRONT COVER QTY: 1
LHS RAIL QTY: 1
RHS MOUNT EXTRUSION QTY: 1
SETUP JIG
MISC5691
QTY: 2
15
16
SCRW0973
SCREW M6X15MM
QTY: 13
SCRW1001
SCREW M6x15
QTY: 14
Issue 2: 01/08/24
