EGR ROLLTRAC Installation Instructions Manual page 5

Ford f-150 6.5ft bed rhd&lhd - compatible with boxlink 2018 onwards

Hide thumbs Also See for ROLLTRAC:

SECTION A

BED PREPARATION

Carefully remove any accessories (Sports Bars, Cabin Guards, etc.) attached to the bed of the vehicle. Thoroughly

wash the vehicle and bed and ensure that all dirt and grease is removed. Allow to dry. Clean the top surfaces of the

bed and tailgate and allow to dry. Carefully remove both Rear Tail Lamps with the appropriate tools and store in safe

place. Retain all hardware for re-installation. IMPORTANT: Remove and retain Tie Down Hooks with mounting plates.

Discard the screws.

CONTINUE ON THE NEXT PAGE

RT0082

Page 5 of 37

Issue 2: 01/08/24
