EGR ROLLTRAC Installation Instructions Manual page 4

T-PATCH
19
RUBBER EXTRUSION
QTY: 1
Drill
Ratchet & Sockets Allen Key
7mm (9/32")
10mm (25/64'')
13mm (33/64'')
50/50
Isopropyl Alcohol/Water
METRIC Tape Measure
RT0082
EGR RollTrac FITTING KIT COMPONENTS IN BAGS
MAIN HARNESS
EGR RollTrac FITTING KIT ADDITIONAL ITEMS
TOOLS REQUIRED - NOT SUPPLIED IN KIT
Holesaw
Ø29mm (11/8")
Ø38mm (11/2")
Centre Punch & Hummer
Allen Key
4mm (5/32'')
ANTI RUST
Rust Inhibitor
3M Primer 94
(preferred) or
equivalent
Ruler x2
BLADE FUSE
CABLE TIE QTY: 2
20
RUBBER
EXTRUSION
QTY: 2
Drill Stop
Drill Bits
Ø5mm (3/16")
2.5mm (3/32'')
4mm (5/32'')
Torque Wrench
Anti-abresion tape to seal
Silicone
holes & slots
1
Number inside a square indicate part number
1
Number inside circle indicate the sequence within a step
1
Number inside the hexagon indicate torque instruction
Page 4 of 37
PANEL CLIP QTY: 1
CABLE TIE QTY: 20
INSTALLATION
INSTRUCTIONS
Scissors
Side Cutters
Silicone Spray
GLOSSARY:
OWNERS
MANUAL
Masking Tape
Fiberglass Tape
Black Cloth Tape
Soapy Water
Issue 2: 01/08/24
