Analog Devices EVAL-KW4501Z User Manual

General Description
The EVAL-KW4501Z demonstration board evaluates and
differentiates the integrated
2-channel operational amplifier. Both channels have a
default gain of G = -1000, and each channel has a different
combination of resistor values.
See Figure 1 for the circuit configuration of each channel;
the resistor values are set as follows: (1) R
= 1kΩ for Channel A; and (2) R
Channel B.
The EVAL-KW4501Z is a companion board to the
Integrated Noise KWIK Lecture and Lab Training Module.
It is part of the KWIK Demo Board family, a series of
instructional and demonstrative evaluation boards that can
be directly plugged into the ADALM2000, Analog Devices
Inc.'s portable, USB-powered, software-defined test and
measurement instrument.
The ADA4510-2, the EVAL-KW4501Z's featured IC, is a
dual-channel, high-precision, low-offset voltage, low-
noise, rail-to-rail input, and output operational amplifier.
This part has a wide 6V to 40V supply voltage operation
range. It can be powered up by the ADALM2000's on-
board ±5V voltage supplies.
The EVAL-KW4501Z uses the 8-pin SOIC version of
ADA4510-2 and accommodates other ICs with the same
footprint and pin configurations. Full specifications for the
ADA4510-2 are available on www.analog.com.
Rev 0; 12/24
O n e A n a l o g W a y , W i l m i n g t o n , M A 0 1 8 8 7 - 2 3 5 6 , U . S . A .
noise of
= 1MΩ and R
F
= 10kΩ and R = 10Ω for
F G
Figure 1. Circuit Configuration of Each Channel
DOCUMENT FEEDBACK
T e l : 7 8 1 . 3 2 9 . 4 7 0 0
Evaluation Board User Guide
Integrated Noise KWIK Demo Board
Features
•
Allows for Quick
Amplifier's Integrated Noise
a
•
Accommodate Other 8-Lead SOIC, Dual-Channel
Operational Amplifiers with Similar Pin Configurations
as DUT
•
Plug-and-Play Feature Facilitates Attachment onto the
ADALM2000 to Run Quick Tests and Measurements in
G
Scopy (Companion Software of ADALM2000)
Evaluation Kit Contents
•
EVAL-KW4501Z Evaluation Board
Equipment Needed
•
ADALM2000 Active-Learning Module
•
USB-A to Micro-USB Cable
•
Computer
Documents Needed
•
ADA4510-2 Data Sheet
•
Integrated Noise KWIK Lecture and Lab Training
Module
•
ADALM2000 User Guide
© 2 0 2 4 A n a l o g D e v i c e s , I n c . A l l r i g h t s r e s e r v e d .
EVAL-KW4501Z
Measurement of Operational
TECHNICAL SUPPORT
