Evaluation Board User Guide
Getting Started
Software Installation
The ADALM2000 driver and Scopy software are necessary to use and control the ADALM2000 device through a
computer.
The quick start procedure to get the ADALM2000 running can be found on the
the links in each step for more details and troubleshooting tips.
For a more detailed walkthrough of the device, refer to the
Hardware Integration
1. Align the pinouts to connect the EVAL-KW4501Z board to the ADALM2000 as shown in
2. Plug in a micro-USB cable to the connectivity port as shown in
computer.
3. Open Scopy. Then click the Preferences icon on the lower-left panel, and select Reset Scopy. See
4. On the Scopy landing page, select the detected ADALM2000 device (also known as M2K), then click Connect. The
program runs a calibration routine and notifies via text in the status console that the device is ready to operate. See
Figure 7.
analog.com
ADALM2000 User Guide for End
Figure 4. Connecting EVAL-KW4501Z to ADALM2000
Figure 5. Connecting the ADALM2000 to the Computer
EVAL-KW4501Z
ADALM2000 Quick Start wiki
User.
Figure
Figure 5 and connect the ADALM2000 into the
page. Follow
4.
Figure 6.
Rev 0 4 of 10
