EmCORE-i2802
Form Factor
3.5" Compact Board
Video
1 x Display Port
2 x Dual Channels 24-bit
Display Port
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
http://arbor-technology.com/
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://arbor-technology.com/
E-mail: info@arbor.com.tw
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
All Rights Reserved.
®
CPU
Soldered onboard Intel
Elkhart Lake Processor
Celeron
N6210 1.2GHz/
®
Atom
x6413E 1.5GHz
®
LAN
2 x Realtek RTL8111
PCIe Gigabit Ethernet
- 1 -
3.5" Compact Board
Quick Installation Guide
Audio
ITS 92HD81B1C5
®
NLGXRAX HDA, Mic-in/
Line-in/ Line-out
I/O
SATA/ USB/ COM/ Mini-
card/ DIO/ Micro SIM
4040280200100P
Version 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmCORE-i2802
Summary of Contents for Arbor Technology EmCORE-i2802
- Page 1 EmCORE-i2802 3.5" Compact Board Quick Installation Guide Version 1.0 Form Factor Audio 3.5" Compact Board Soldered onboard Intel ITS 92HD81B1C5 ® Elkhart Lake Processor NLGXRAX HDA, Mic-in/ Celeron N6210 1.2GHz/ Line-in/ Line-out ® Atom x6413E 1.5GHz ® Video 1 x Display Port...
-
Page 2: Packing List
Packing List Before you begin installing your Compact Board, please make sure that the following materials have been shipped: 1 x EmCORE-i2802 3.5” Intel ® Elkhart Lake Celeron ® N6210 Compact Board / Intel ® Elkhart Lake Atom ® x6413E Compact Board 1 x Quick Installation Guide If any of the above items is damaged or missing, contact your vendor immediately. -
Page 3: Board Dimensions
Board Dimensions Unit: mm - 3 -... -
Page 4: Specifications
Specifications Form Factor 3.5" Compact Board Soldered onboard for Intel ® Elkhart Lake / Celeron ® N6210 1.2GHz/ Atom ® x6413E 1.5GHz Processor 1 x DDR4 SO-DIMM socket, up to 16GB DDR4 3200 MT/s Memory SDRAM BIOS AMI BIOS Watchdog Timer 1~255 levels reset Serial Port 6 x Serial Ports... - Page 5 Jumpers and Connectors Location on Top side (10)USB3 (12)JPWRSW1 (14)LVDS2 (15)LVDS1 (11)JFRT1 (9)USB2 JPWR1 (8)SPK1 (13)AUDIO1 (16)SATA1 (26)MC2 (7)DP1 (27)SIM1 USB1 (25)MC1 (17)SATAPWR1 (6)LAN1 JINV2 JINV1 (18)SATA2 (29)JLPC1 (28)BAT1 (19)SATAPWR2 (5)LAN2 (20)COM5 (4)COM2 /COM3 (21)COM6 (22)FAN1 (2)COM1...
-
Page 6: Jumpers & Connectors Quick Reference
Jumpers & Connectors Quick Reference Jumpers Jumper Description ➊ AT/ATX Power Mode Selection JPWR1 ➋➌ LVDS1, 2 LCD Voltage Selection JVLCD1, 2 ➍ CMOS Setting JBAT1 ➎➏ LVDS1, 2 LCD Inverter Voltage Selection JINV1, 2 Connectors Connector Description (1)CN1 DREWR Connector (2)COM1 RS-232 Serial Port Connector (3)COM4... - Page 7 Jumpers Jumpers Connectors Connectors ➊ (1)CN1: DREWR Connecter JPWR1: AT/ATX Power Mode Selection Connector type: 2.0mm pitch 1x3 pin header Connector type: RJ-11 Connector Power Mode Selection Pin Description FRAME GND ATX Mode (Default) DRWER1 SW_IN AT Mode DRWER2 ➋➌ JVLCD1, 2: LVDS1, 2 LCD Voltage Selection (2)COM1: RS-232 Serial Port Connector...
- Page 8 (4)COM2/COM3: RS-232 Serial Port (9)(10)USB2, 3: USB Hub Connector Connector Connector type: 1.25mm pitch 1x5 pin header Connector type: External 9-pin D-sub male connector. Description Desc. Desc. USB_+5V USB- USB+ (11)JFRT1: Switches and Indicators (5)(6)LAN2, 1: RJ-45 LAN and USB 2.0 Stack Connectors Connector type: 2.0mm pitch 2x4 pin wafer connector Desc.
- Page 9 (14)(15) LVDS2, 1: LVDS Connector (16)(18)SATA1, 2: SATA Connector Channel 0, 1 Connector type: 1.25mm pitch 2x20 pin connector, supporting 24-bit dual channels Connector type: SATA Connector Pin Description Pin Description The pin assignments conform to the industry standard. LCD_ LCD_ VDD(+3.3V/+5V) VDD(+3.3V/+5V)
- Page 10 (23)PWRIN1: DC +12V Power Input (28)BAT1: Battery Connector Connector Connector type: 1.25mm pitch 1x2-pin connector. Connector type: 2.5mm pitch 1x8 pin header Description Pin Description VIN: 8V~13.2V Battery Power VIN: 8V~13.2V (29)JLPC1: LPC to 80 Port Debug Card Connector +5V LED Connector type: 1.25mm pitch 2x5 pin header COM1 DSR Pin Desc.
