Form Factor
3.5" MiniBoard
VGA
Dual Channels 18-bit
LVDS/ Analog RGB/
TV-out
I/O
Mini-PCI/ SATA/ USB/
COM/ LPT
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
2011 All Rights Reserved.
®
EmCORE-i2702
CPU
Soldered onboard Intel®
Atom™ N270 1.6GHz
CPU
LAN
2 x Realtek 8111C PCIe
Gigabit Ethernet
Quick Installation Guide
- 1 -
3.5" Miniboard
Chipset
Intel® 945GSE
Intel® ICH7M
Audio
Realtek ALC655 AC97
Audio Codec, Line-in/ Line-
out/ Mic-in
4041270200110P
Version 1.1
Advertisement
Table of Contents
Related Manuals for Arbor Technology EmCORE-i2702
Summary of Contents for Arbor Technology EmCORE-i2702
-
Page 1: Quick Installation Guide
EmCORE-i2702 3.5” Miniboard Quick Installation Guide Version 1.1 Form Factor Chipset 3.5” MiniBoard Soldered onboard Intel® Intel® 945GSE Atom™ N270 1.6GHz Intel® ICH7M Audio Dual Channels 18-bit 2 x Realtek 8111C PCIe Realtek ALC655 AC97 LVDS/ Analog RGB/ Gigabit Ethernet... -
Page 2: Packing List
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EmCORE-i2702 3.5” Compact Board 1 x Driver CD 1 x Quick Installation Guide Ordering Information EmCORE-i2702 Intel® N270 3.5” Compact Board... -
Page 3: The Installation Paths Of Cd Driver
The Installation Paths of CD Driver Windows 2000 & XP Driver Path CHIPSET \CHIPSET\INF 9.2.0.1021 \GRAPHICS\INTEL_2K_XP_32\1432 \ETHERNET\REALTEK\8111_WINXP_5764 AUDIO \AUDIO\REALTEK_AC97\Win2K_XP_A406 Windows 7 Driver Path CHIPSET \CHIPSET\INF 9.2.0.1021 \GRAPHICS\INTEL_WIN7_32\1930 Windows 7 built-in LAN driver AUDIO \AUDIO\REALTEK_AC97\Win7_32_64_6305 - 3 -... -
Page 4: Specifications
Specifications Form Factor 3.5” Compact Board Intel® Atom™ N270 CPU 1.6GHz w/ 533MHz FSB Chipset Intel® 945GSE + Intel® ICH7M 1 x 200-pin DDR2 SO-DIMM Socket supporting 533MHz SDRAM System Memory up to 2GB (Optional soldered onboard 1GB DDR2 SDRAM) Integrated Intel®... -
Page 5: Board Dimensions
Board Dimensions 8.15 12.80 27.41 26.76 31.50 61.65 10.55 10.00 0.00 3.43 8.84 24.88 32.64 22.49 14.59 17.15 17.15 142.77 13.00 68.50 13.90 65.50 16.80 Unit: mm - 5 -... - Page 6 Jumpers/ Connectors Quick Reference Connectors Label Function Keyboard & Mouse KBMS1 Connector PWR1&2 DC 12V Power Input LAN1, AUDIO1 Audio Connector Ethernet Connectors LAN2 COM1~2 Serial Port Connectors LPT1 Parallel Port Connector DIO1 Digital I/O Connector LVDS1 LVDS Connector SYSF1 Fan Connector MINI-PCI1 Mini-PCI Socket...
-
Page 7: Jumpers & Connectors Location
Jumpers & Connectors Location LVDS1 PWR1&2 INV1 JVLCD1 COM1 SO-DIMM (On bottom side) VGA1 SYSF1 PWR3 JBAT1 JPWR1 JSMB1 IDE1 COM2 KBMS1 9 10 SATA1 LAN1 SATA2 (On bottom side) USB1 JCOM2 DIO1 MINI-PCI1 USB2 LPT1 JRS2 LAN2 JFRT1 AUDIO1 - 7 -... - Page 8 Jumpers Connectors PWR1&2: ATX +12V Connector JPWR1: AT/ATX Power Mode Selection PRW1&2 supplies the CPU operation ATX +12V Connector type: 2.54mm pitch 1x2-pin headers. (Vcore). Mode Desc. Desc. Short AT mode Open ATX Mode (Default) +12V +12V PWR3: ATX Feature Connector JRS2: COM2 RS-232/ 422/ 485 Selection Connector: onboard 3-pin power connector Connector type: 2.00mm pitch 2x3-pin headers.
- Page 9 LVDS1: LVDS Connector IDE1: Primary IDE Connector Connector type: DF-13-30DP-1.25V connector Connector type: 2.00mm pitch 2x22-pin box headers. Pin Desc. Pin Desc. TX2CLK+ TX1CLK+ Description Description TX2CLK- TX1CLK- RESET# DATA7 DATA8 TX2D0+ TX1D0+ DATA6 DATA9 TX2D0- TX1D0- DATA5 DATA10 DATA4 DATA11 TX2D1+ TX1D1+...
- Page 10 CF1: Compact Flash Type II Socket JCOM2: RS-422/485 Output Connector Connector type: 2.00mm pitch 1x4-pin box wafer connector. Pin RS-422 RS-485 DATA+ DATA- AUDIO1: AUDIO Connector Connector type: 2.00mm pitch 2x5-pin box headers. Pin Desc. Desc. Line_In_Left 2 Line_In_Right MIC2 Description Description 9 10...
- Page 11 JFRT1: Switches and Indicators CN2: LAN2 LED Indicator Connector type: 2.54mm pitch 2x2-pin headers. It provides connectors for system indicators that provides light indication of the computer activities Description Pin Description and switches to change the computer status. Connector type: 2.54mm pitch 2x5-pin headers. LED_Y- LED_Y+ LED_G-...
- Page 12 SYSF1: Fan Connector SYSF1 is a 3-pin headers for the system fan. The fan must be a +12V fan. Description +12V FAN_Detect VGA1: Analog RGB Connector Connector type: VGA: D-Sub 15-pin female Pin Desc. Pin Desc. Desc. GREEN VDDAT BLUE HSYNC VSYNC VDCLK...
- Page 13 This page is intentionally left blank. - 13 -...
