1. Connect an Allure EC-Smart-Vue Series Communicating Sensor
sensor to the controller with a Cat 5e patch cable. Wait for the dis-
play to show the room temperature.
2. Press and hold the Menu button
password menu. 10000 is shown on the display.
3. Use the down button to set the number to 9995 (this is the de-
fault password).
4. Press the Menu button
ting the password, the GEN CFG menu appears on the display.
5. Press the down button once to enter the GEN CFG submenu.
6. Use the Menu button several times until BAUD RATE appears
on the display. The current controller's BAUD rate is shown.
7. Use the up and down buttons
rate. The AUTO setting detects and uses the current baud rate be-
ing used by the BACnet MS/TP network.
8. Press the Menu button
9. Press and hold the Menu button
figuration menu.
for 5 seconds to enter the
Screen Timeout: 15 seconds
OR
Screen Timeout: 15 seconds
OR
to submit the password. Upon submit-
Screen Timeout: 30 seconds
OR
Screen Timeout: 30 seconds
OR
to set the controller's Baud
once to apply the value.
for 5 seconds to exit the con-

Wireless Installation

When connected to a Wireless Receiver, controllers can receive input
signals from a wide selection of wireless devices. Compatible wireless
devices include temperature sensors, duct sensors, window/door con-
tacts and light switches. These devices are easy to install, and can be
mounted on a wide range of building materials.
Before connecting any wireless equipment to the controller,
refer to the Open-to-Wireless Solution Guide.

Connecting the Wireless Receiver

The Wireless Receiver is connected to the controller using a 2m (6.5ft)
telephone cable with 4P4C modular connectors at both ends. Do not
exceed this cable length. The Wireless Receiver's telephone socket is
located inside the device. To locate it, open the Wireless Receiver by
separating its front and back plates.
Figure 16: Location of the Wireless Receiver's telephone
socket
Connecting to the Controller's Wireless Port
Each controller has a wireless port in which one end of the Wireless
Receiver's telephone cable plugs in.

Terminal Block Cover

In certain jurisdictions, terminal block covers are required to meet local
safety regulations. Terminal block covers are available for all controllers
and are used to conceal the controllers' wire terminals. Terminal block
covers are optional and are sold as peripherals.
The terminal block cover can be clipped on to the controller as shown
below.
Figure 17: Terminal block covers
