3. Press the down button
fault password).
4. Press the Menu button
ting the password, the GEN CFG menu appears on the display.
5. Press the down button
6. Press the Menu button
on the display. The current controller's Subnet ID is shown.
7. Use the up and down buttons
ID to 1. Tip : Hold down either the up or down button to fast-advance
the display value.
8. Press the Menu button
9. Press and hold the Menu button
figuration menu.
The an Allure EC-Smart-Vue Series Communicating Sensor can now
be used to go from one ECB series controller to the next for commis-
sioning purposes.
Commissioning ECB-Series Controllers
When using an Allure EC-Smart-Vue Series Communicating Sensor for
commissioning ECB Series controllers (the DIP switch located on the
faceplate is set to 0 (all off) and before code is downloaded to the con-
troller from EC- gfx Program ), connect an Allure EC-Smart-Vue Series
Communicating Sensor to the controller with its Subnet ID set to 1.
Set the connected controller's MAC Address as follows:
1. Connect an Allure EC-Smart-Vue Series Communicating Sensor to
the controller with a Cat 5e patch cable. Wait for the display to show
the room temperature.
2. Press and hold the Menu button
password menu. 10000 is shown on the display.
10 / 14
Screen Timeout: 15 seconds
OR
to set the number to 9995 (this is the de-
Screen Timeout: 15 seconds
OR
to submit the password. Upon submit-
Screen Timeout: 30 seconds
OR
once to enter the GEN CFG submenu.
several times until SUBNET ID appears
Screen Timeout: 30 seconds
OR
to set the controller's Subnet
once.
for 5 seconds to exit the con-
for 5 seconds to enter the
3. Use the down button to set the number to 9995 (this is the de-
fault password).
4. Press the Menu button
ting the password, the GEN CFG menu appears on the display.
5. Press the down button
The MAC ADDRESS menu is shown with the current controller's
BACnet MAC Address.
6. Use the up and down buttons
Address. Only addresses from 1 to 127 are recommended to be
used.
7. Press the Menu button
8. Press and hold the Menu button
figuration menu.
Once the controller's network is operational, the controller can be pro-
grammed with EC- gfx Program. For each Allure EC-Smart-Vue Series
Communicating Sensor, set its Subnet ID number to the block number
of its associated ComSensor block in EC- gfx Program. This is done in
the sensor's GEN CFG menu under SUBNET ID.
Setting the BAUD Rate (optional – ECB
series controllers only)
By default, the BAUD rate for the controller is set to automatically de-
tect the current communication BAUD rate of the connected BACnet
MS/TP network (AUTO). This is the preferred setting for a controller.
However, at least one controller on the BACnet MS/TP network data
bus must have its BAUD rate set. The preference is to set the building
controller's BAUD rate (if present). Otherwise, set the BAUD rate on
one controller that will set the BAUD rate for all other controllers (to act
as the master for setting the BAUD rate).
When the Baud rate is set to AUTO, the controller cannot
initiate any communication until it has detected the baud
rate of the BACnet MS/TP network. If all controllers on the
BACnet MS/TP network are set to AUTO, then all
controllers will not communicate.
Set the connected controller's BAUD rate as follows:
Screen Timeout: 15 seconds
OR
Screen Timeout: 15 seconds
OR
to submit the password. Upon submit-
Screen Timeout: 30 seconds
OR
once to enter the GEN CFG submenu.
Screen Timeout: 30 seconds
OR
to set the controller's MAC
once to apply the value.
for 5 seconds to exit the con-
